Having worked up to London Paddington earlier in the day, the Diesel Traction Group owned Class 52 “Western” diesel-hydraulic No. D1015 ‘Western Champion’ passes through Pangbourne at the head of 1Z56 1352 London Paddington to Birmingham New Street charter train. Originally an empty coaching stock movement to Burton, it was instead tuned into a main line test run for No. D1015 and opened up for public use as a joint operation by UK Railtours and Pathfinder Tours named “The One Way Wizzo”. The “Western” worked the tour as far as Bescot Yard, from where Class 57 No. 57303 took over the last into New Street before taking the ECS forward to Burton-on-Trent – 14/04/2024
April 14th 2024 to April 24th 2024
On Sunday 14th April 2024, preserved Class 52 “Western” diesel-hydraulic locomotive No. D1015 ‘Western Champion’ worked a loaded test run from London Paddington to Birmingham New Street, supported by GBRf Class 57 No. 57303 which was utilised as a passenger carrying one way rail tour. No. D1015 ran light into Paddington and then headed up the “One Way Wizzo” as far as Bescot Yard, with No. 57303 taking charge for the final leg into New Street. After the tour, ‘Western Champion’ returned to her base on the Severn Valley Railway.
I was quite intrigued with the idea of trying to photograph both the Western’s light engine move as well as the loaded test run itself, so devised a plan for a visit to a National Trust property as a day-out for Yoshi and Caroline. Checking out the route of the Great Western main line on Google maps, I settled on Basildon Park as our heritage destination as the railway runs very close to the estate. On the day, I checked out potential photographic spots, but discounting these, back-tracked slightly to Pangbourne railway station as the car park is ideally situated for photography as long as you can position yourself above the line-side fencing; remembering to stay safe at all times!
Pangbourne station is located close to the village centre, with the main station buildings on the opposite side of the railway to the village. It has two platforms, one on each of the relief (slow) lines, whilst the fast lines pass behind the station. The platforms are linked to each other and the station entrance, on the up relief platform, by a pedestrian underpass. The station once had four platforms with those situated on the main fast lines now no longer in situ.
Exterior of Pangbourne railway station. The station is on the original line of the Great Western Railway, which was opened in stages: the portion between Reading and Steventon opened on 1st June 1840, with Pangbourne being the first station west out of Reading – 14/04/2024All services at Pangbourne are operated by Great Western Railway (GWR) using Class 387 EMU’s. The typical off-peak is two trains per hour in each direction between London Paddington and Didcot Parkway. On Sundays, the service is reduced to hourly in each direction. Screenshot of Class 387 Electrostar electric multiple unit (EMU) No.’s 387169 & 387170 depart Pangbourne working 2N42 1426 Reading to Didcot Parkway – 14/04/2024Great Western Railway Intercity Express Train (IET) pass Pangbourne on the fast lines situated behind the platforms at Pangbourne. Class 800 No. 800311 passes Pangbourne working 1A18 1300 Bristol Temple Meads to London Paddington – 14/04/2024CrossCountry trains also pass Pangbourne. Screenshot of CrossCountry Class 221 Super Voyager No. 221133 works 1O16 1124 Manchester Piccadilly to Southampton through Pangbourne – 14/04/2024
While waiting for No. D1015 to pass us on her way to London Paddington, the local security operated by Land Sheriffs Ltd pulled into the car park and parked up casting a weather eye over my activity. As the Western was still a good few minutes off, I strolled over for a chat. The two security guards were really friendly and knew just what I was waiting for. They were, however, surprised to learn that the heritage diesel-hydraulic locomotive was making a solo pass prior to its railtour work as they had been charged with keeping an eye on proceedings further up the line at Didcot when the “One Way Wizzo” was due to pass later that afternoon as the train was sure to attract much attention from railway enthusiasts. Satisfied that I was not a security risk, the Land Sheriffs left me to await the first appearance of No. D1015.
Class 52 No. D1015 ‘Western Champion’ runs light engine towards Pangbourne railway station working 0Z55 1020 Kidderminster SVR to London Paddington – 14/04/2024
It was a good couple of hours before ‘Western Champion’ was timed to pass Pangbourne on her way to Bescot, so we decamped to National Trust Basildon Park where we enjoyed a woodland walk taking in the bluebells before Caroline took a tour of the mansion house and Yoshi and I headed back to the railway station car park for another shot at photographing No. D1015, this time at the head of a rake of carriages.
Yoshi amongst the bluebells in the wooded parkland at Basildon Park – 14/04/2024Yoshi at National Trust Basildon Park. The estate was purchased by Francis Sykes in 1771. Sykes had made his fortune in the East India Company and required a home befitting his status. He demolished the old house and employed architect John Carr to build the Bath-stone mansion which exists today. The property was gifted to the National Trust in 1978 by Lord and Lady Iliffe who had bought Basildon Park in 1952 – 14/04/2024Class 52 “Western” diesel-hydraulic No. D1015 ‘Western Champion’ passes Pangbourne with “One Way Wizzo” 1Z56 1352 London Paddington to Birmingham New Street – 14/04/2024
Video of Class 52 “Western” diesel-hydraulic No. D1015 ‘Western Champion’ passing Pangbourne – 14/04/2024
Monday 15th April we were back at Poole railway station in readiness for GBRf Class 73 No.’s 73962 ‘Dick Mabbutt’ and 73961 ‘Alison’ working the monthly 1Q51 11:15 Derby RTC to Eastleigh Yard via Weymouth test train.
Video screenshots of GBRf Class 73 No.’s 73962 ‘Dick Mabbutt’ and 73961 ‘Alison’ working 1Q51 11:15 Derby RTC to Eastleigh Yard via Weymouth – 15/04/2024
Video of 1Q51 11:15 Derby RTC to Eastleigh Yard via Weymouth at Poole – 15/04/2024
The following day, Tuesday 16th April, we were out to see GBRf Class 57 No. 57303 once again, this time performing electric multiple unit drag duties, hauling South Western Railway (SWR) refurbished Class 458 No. 458421 and 508 barriers as 5Q64 1534 Southampton Central to Bournemouth T&R.S.M.D. having worked down from Widnes Transport Tech as far as Wembley Receptions 1-7 the previous day before progressing into Dorset.
GBRf Class 57 No. 57303 leading SWR Class 458 No. 458421 and 508 barriers towards Parkstone railway station as 5Q64 1534 Southampton Central to Bournemouth T&R.S.M.D. – 16/04/2024After running round its train, GBRf Class 57 No. 57303 hauls SWR Class 458 No. 458421 up Parkstone Bank working 5Q64 1534 Southampton Central to Bournemouth T&R.S.M.D. – 16/04/2024
Later the same day, No. 57303 departed Bournemouth depot with un-refurbished Class 458 No. 458513 as 5Z66 2018 Bournemouth T&R.S.M.D to Eastleigh East Yard. The formation was scheduled to stable at Eastleigh overnight before proceeding to Widnes Transport Tech on Wednesday 17th. We saw this formation at Poole on the first leg of its journey.
Screenshot of GBRf Class 57 No. 57303 with Class 508 barrier coaches and SWR Class 458 No. 458513 arrives at Poole working 5Z66 2018 Bournemouth T&R.S.M.D to Eastleigh East Yard. The train heads out to Poole Storage Sidings – 16/04/2024Having left the Class 458 in Poole Storage Sidings, GBRf Class 57 No. 57303 runs light engine into Poole railway station before heading back to attach to the London end of its train – 16/04/2024
GBRf Class 57 No. 57303 on SWR Class unit drags – 16/04/2024
Following the successful restoration of LSWR Adams T3 Class No. 563, the team at the Swanage Railway are now turning their attention to their next challenge, that of returning LSWR T9 Class No.120 to steam in time for its 130th birthday in 2029 resplendent in Olive green livery. Thursday 18th April was therefore an eventful one for No.120 as she departed the Swanage Railway by road for transit to The Flour Mill Locomotive Repair Workshop in Lydney, Gloucestershire. The Flour Mill is a listed former colliery electricity generating station which was converted to a railway workshop between 1995 and 1996. The Flour Mill Ltd operates the business undertaking work repairing and overhauling steam locomotives. We popped over to the Purbeck line to witness the Victorian locomotive being collected from Swanage by resident diesel Class 33 No. D6515 (33012) ‘Lt. Jenny Lewis RN’. The pairing then travelled up to Arne Road sidings where No.120 was to be placed on a road low-loader.
The T9 is owned by the National Railway Museum (NRM) and agreement has been reached where the condition of the locomotive will be assessed ahead of a commitment to return her to steam for further service on the Swanage Railway.
Designed by Dugald Drummond and built in 1899 at Nine Elms works, No.120 was a member of the T9 class of locomotives, affectionately known as the “Greyhounds” for their swift performances on the West of England main lines.
LSWR 4-4-0 T9 Class No.30120 at Swanage – 18/04/2024
Altogether, sixty-six T9 locomotives were built, with No.120 being the only survivor. She was withdrawn from regular service in 1961 and painted in London South Western Railway (LSWR) ‘Pea Green’ livery, colours – inappropriate as she was modified with a superheater by Robert Urie and as a consequence her appearance was substantially altered from her early days. However, in this guise she hauled special trains for a few years before becoming part of the National Collection. After spells of service on the Mid-Hants Railway, at Swanage and on the Bodmin & Wenford Railway, No. 120 returned to Swanage in 2017 and became a vital part of the fleet until her boiler certificate expired. During her time at Swanage the locomotive proved a powerful but economic machine, popular with both crews and visitors alike. Her restoration will allow the Swanage railway to develop a more sustainable locomotive fleet into the future as the T9, like the T3, is perfectly sized for the heritage branch.
Swanage resident Class 33 No.D6515 (33012) ‘Lt. Jenny Lewis RN’ having coupled up to 4-4-0 T9 Class No.30120 in readiness of forming 6Z12 1652 Swanage to Arne Road Siding – 18/04/2024Crompton No. D6515 (33012) ‘Lt. Jenny Lewis RN’ is owned by the 71A Loco Group, and returned to Swanage in time for the May 2011 Diesel Gala after undergoing overhaul at Eastleigh works. She is seen here reversing into Swanage railway station with 4-4-0 T9 Class No.30120 – 18/04/2024Southern Railway 4-6-2 “West Country” Class No. 34028 ‘Eddystone’ at Swanage having backed onto the coaching stock of the 2N10 1640 Swanage to Norden service – 18/04/2024Southern Railway 4-6-2 “West Country” Class No. 34028 ‘Eddystone’ departs Swanage working 2N10 1640 Swanage to Norden – 18/04/2024Class 33 No.D6515 (33012) ‘Lt. Jenny Lewis RN’ hauls 4-4-0 T9 Class No.30120 away from Swanage working as 6Z12 1652 Swanage to Arne Road Siding – 18/04/2024Class 33 No.D6515 (33012) ‘Lt. Jenny Lewis RN’ and 4-4-0 T9 Class No.30120 on the approach to Harmans Cross working 6Z12 1652 Swanage to Arne Road Siding – 18/04/2024
The Swanage Railway Trust are hoping to raise £50,000 for this project, which will enable No. 120 to be dismantled and assessed at the Flour Mill. Following this, a report will be produced detailing the work required to return 120 to service, including an assessment of the cylinder block and whether this needs to be replaced. If the report is favourable, the Trust can proceed to the next stage of the overhaul later in the year. Should it be decided the locomotive is not a suitable contender for restoration, the remainder of the £50,000 will see No. 120 re-assembled and returned to the NRM for further display.
Class 33 No.D6515 (33012) ‘Lt. Jenny Lewis RN’ arrives at Arne Road with 4-4-0 T9 Class No.30120 in tow working 6Z12 1652 Swanage to Arne Road Siding – 18/04/2024
Video of T9 Class No.30120 being hauled to Arne Sidings on the Swanage Railway – 18/04/2024
Engineering Work took place in the Wareham area over the weekend of 20th / 21st April 2024. The sidings to the east of Wareham railway station were renewed, ballast was refreshed at Worgret Junction and the footbridge at Wool railway station received attention. Two engineering trains were engaged for the work; 6G13 2212 Eastleigh East Yard to Wareham top and tailed by GBRf Class 66 No.’s 66795 & 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ and 6C03 1939 Eastleigh East Yard to Holton Heath in the sole charge of Colas Class 66 No.66850 ‘David Maidment OBE’. Two other associated workings featured 4-wheeler Track Machine Colas Tamper No. DR73931 forming 6J86 1844 Woking Up Yard Reception to Wool MOD Siding GBRf and Pandrol Jackson Plain Line Stoneblower No. DR80205 working as 6U37 2103½ Horsham Up T.C. to Holton Heath.
Screenshot of GBRf Class 66 No. 66795 at Poole leading on 6G13 2212 Eastleigh East Yard to Wareham – 20/04/2024Screenshot of GBRf Class 66 No. 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ passes through Poole at the rear of 6G13 2212 Eastleigh East Yard to Wareham – 20/04/2024Screenshot of Colas Class 66 No.66850 ‘David Maidment OBE’ passing Poole working 6C03 1939 Eastleigh East Yard to Holton Heath – 20/04/2024Wareham Railway Station – 21/04/2024A hand written note informs us that the pedestrian crossing at Wareham railway station is closed due to engineering work – 20/04/2024New track panels stacked adjacent the unused signal box at Wareham – 20/04/2024Work continues at Wareham – 20/04/2024A view up the line towards Wareham sidings which would be partially renewed during the weekend engineering works- 20/04/2024A Road Rail Vehicle (RRV) at work in Wareham – 21/04/2024Pandrol Jackson Plain Line Stoneblower No. DR80205 used for the initial levelling of track after it has been freshly installed awaits the call of duty at Holton Heath – 21/04/2024
The Class 66 hauled engineers trains departed the possession area in the early hours of Monday 22nd reporting as 6G13 0230 Bournemouth to Eastleigh East Yard and 6C03 0330 Bournemouth to Eastleigh East Yard.
Holton Heath railway station – September 2022
20th April was the 35th anniversary of a collision which occurred at Holton Heath in 1989. Tragically, Bournemouth train driver Clive Brooker lost his life in the accident. The archived report can be found here.
Plaque in memory of Driver Clive Brooker situated at Hamworthy railway station; “At about 1202, a light locomotive, that is one travelling without a train, collided with the rear of a freight train at Holton Heath. I regret to report that the driver of the light locomotive… died as a result of the accident. The driver and the guard of the freight train suffered minor injuries.
On a dry clear day, the diesel locomotive, No. 33107, was travelling at speed under clear signals along the Up line between Wareham and Hamworthy Junction, when it struck the rear of the 1145 Wool to Eastleigh freight train 6W54 as it was accelerating away from a stand after carrying out shunting duties at Holton Heath Siding. The freight train consisted of eight wagons hauled by an electro-diesel locomotive No. 73002; the rearmost wagon being the Type VAA four-wheeled covered van with long sliding doors and loaded with bagged and palletised ballcla.”
Wednesday April 24th 2024 and it was the turn of Network Rail’s (NR) New Measurement Train (NMT) to visit Weymouth via the western route from Yeovil Pen Mill. Having missed out the Dorset seaside town because of line closures in March the train, which monitors and records track condition information at speeds up to 125mph, was in the hands of former High Speed Train Class 43 power cars No.’s 43274 and 43357 this month. Yoshi and I visited Upwey to see the outward and return legs.
In its Colas branded East Midlands Railway (EMR) livery, Class 43 High Speed Train power car No. 43274 leads on the approach to Upwey working the New Measurement Train 1Z22 0747 Derby Railway Technical Centre to Bristol Kingsland Road via Weymouth – 24/04/2024At the rear of the New Measurement Train – reporting as 1Z22 0747 Derby RTC to Bristol Kingsland Road via Weymouth – in de-branded CrossCountry livery Class 43 High Speed Train power car No. 43357 passes through Upwey on its way to Weymouth – 24/04/2024Class 43 High Speed Train power car No. 43357 forming the New Measurement Train 1Z22 0747 Derby Railway Technical Centre to Bristol Kingsland Road via Weymouth passes South Western Railway Class 444 No. 444024 forming 1W27 1335 London Waterloo to Weymouth at Upwey – 24/04/2024
Video of the Dorset HST Hew Measurement Train – 24/04/2024 (with thanks to da_bucklet967 and G E Barrett for additional video content)
Train drivers union, ASLEF, have announced fresh strikes and an overtime ban taking place between Monday 6th May and Saturday 11th May 2024. Train Operating Companies (TOC) in Dorset affected by strike action days are SWR on Tuesday 7th May and GWR on Wednesday 8th May when revised services will run, with short-notice cancellations possible.
That’s it for another belated blog entry, thanks for joining us looking back on our railway themed adventures! We appreciate your comments, corrections and feedback. We’ll be back with another update soon. Until then, be seeing you!
Adams LSWR 4-4-0 T3 No.563 and SECR 0-6-0 O1 No. 65 passing Corfe Castle during the Swanage Railway’s Victorian Weekend – 23/03/2024
March 23rd 2024 to March 31st 2024
As promised last time, in this blog entry, we are going to share our photos and videos from our visit to Swanage Railway’s “Victorian Weekend” event which saw the resident Adams T3 No. 563 in service along with SECR Class O1 No. 65 visiting from the Bluebell Railway. The special gala weekend ran from Friday 22nd to Sunday 24th March. I was sorely tempted to visit for all three days, if only to see the first train of the day which involved both the T3 and O1 double heading from Swanage to Norden. In the event, I only made the journey on the Saturday. I have mixed feelings about my photographs recording the two Victorian locomotives working in tandem.
But before Yoshi and I went off to Swanage, we had an engineers train to find in the Branksome area. Overnight a GBRf pair of Class 66 locomotives had operated as 6N75 2353 Eastleigh East Yard to Branksome, with the engineering possession in place from just east of Branksome up to Seldown Junction points near Poole High Street Level Crossing. Looking at the live rail maps provided by websites such as Open Time Trains, the train head code was reporting as sitting in Branksome railway station. After a quick look in at the station, we actually found the train sitting the other side of Branksome viaduct, the lead locomotive obscured by trees. However, I managed a record shot of No. 66730 ‘Whitemoor’ which was positioned at the rear of its train before making my way to Corfe Castle on the Swanage Railway.
GBRf Class 66 No. 66730 ‘Whitemoor’at rest on the rear of engineering train 6G12 2353 Eastleigh East Yard to Branksomeatop bridge E20/23 BML2 Electricity Works between Branksome and Bournemouth – 23/03/2024
As well as the two Victorian steam locos in action for their Victorian gala, Swanage residents Southern Railway (SR) 4-6-2 West Country Class No. 34028 ‘Eddystone’ and SR 2-6-0 U Class No. 31806 were also hauling trains. All four locomotives were facing boiler first out of Swanage which limited photographic variety somewhat, but that didn’t in any way diminish my enjoyment and the hard work put in by all concerned involved with running the event.
The first train each morning of the Swanage Railway three day Victorian Weekend gala was double headed by the two Victorian era locomotives; Adams LSWR 4-4-0 T3 No.563 and SECR 0-6-0 O1 No. 65, seen here with Corfe Castle as a backdrop as the duo approach Norden – 23/03/2024SR 2-6-0 – U Class No. 31806 approaches Harman’s Cross – 23/03/2024A wonderful piece of planning saw No. 563 depart Swanage with her train to Norden as No. 65 backed into the station area – 23/03/2024No. 563 gets the token for the single line towards Harman’s Cross and No. 65 runs bak to couple on to her train in the bay platform at Swanage Railway station. – 23/03/2024Adams LSWR 4-4-0 T3 Class No.563 makes a fine sight on departure at Swanage – 23/03/2024Built in 1896, O1 Class No. 65 is the very last surviving South Eastern Railway (SER) locomotive and was rebuilt in 1908 by the South Eastern and Chatham Railway (SECR). The locomotive was purchased from British Railways in 1963 by the Lewis-Evans family for the scrap value of £850 and has been based at the Bluebell Railway since 1997. The Lewis-Evans family decided to sell No. 65 during the latter part of 2021, the locomotive being purchased by the Bluebell Railway Trust securing the locomotive for the heritage line. No. 65 is seen at Woodhyde on the approach to Afflington Bridge which carries the A351 over the railway – 23/03/2024122 locomotives of the O class were built between 1878 and 1899. No. 65 engine was withdrawn by British Railways in 1961, its major claim to fame being the working of the last railtour to run over the Hawkhurst branch in Kent, along with C class No. 31592, which is also preserved at the Bluebell Railway. No. 65 is seen at Woodhyde hauling Swanage Railways Class 117 Diesel Multiple Unit – 23/03/2024SR 2-6-0 – U Class No. 31806 nears Townsend Lane bridge – 23/03/2024SR 4-6-2 West Country Class No. 34028 ‘Eddystone’ at Woodhyde – 23/03/2024One final capture of visiting locomotive SECR 0-6-0 O1 Class No. 65 as she steams up to Corfe Viaduct with a train bound for Norden – 23/03/3034
Video of Swanage Railway’s Victorian Weekend from 23/03/2024
Swanage Railway’s ‘Save Your Railway’ appeal, launched in November 2023, has so far successfully raised £120,000 of the £450,000 target. If you would like to help please click here.
After our Purbeck visit, we popped back to Branksome (of course we did!) so Yoshi could get an update on the maintenance work taking place on the points into the depot at the east end of the railway station. I was pleased the GBRf Class 66’s had moved up with their train which was resting in full sunlight looking very photogenic.
GBRf Class 66 No. 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ with sister loco No. 66730 ‘Whitemoor’ stationary on the approach to Branksome railway station – 23/03/2024Work progresses on the points into Bournemouth depot watched by GBRf Class 66 No.’s 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ and 66730 ‘Whitemoor’ – 23/03/2024A road-rail vehicle at work in Branksome railway station -23/03/2024Yoshi took it upon himself to inspect the engineering work taking place at Branksome. Although, he is looking the wrong way in this image – 23/03/2024Another view of the activity taking place at Branksome with GBRf Class 66 No. 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ – 23/03/2024Balfour Beatty’s 08-4X4/4S-RT tamper No. DR73950 ‘Tamper Tantrum’ operating under head code 6Q04 at Seldown, Poole – 24/03/2024In October 2021, both of Balfour Beatty’s 08-4X4/4S-RT tampers were named following a competition involving schools. Rather than cast plates, the names are applied in transfers on the main bodyside adjacent to the Balfour Beatty name. The machines also carry details of the first names of the child who selected each respective name, their class year and the name plus the logo of their school. No. DR73950 ‘Tamper Tantrum’ is seen here near Seldown Junction at Poole and was named by Chloe, aged 8, at Rockliffe Manor Primary School. It’s sister machine, No. DR73949 was named ‘Tiny Tamper’ – 24/03/2024
Monday morning we were up early and popped over to Poole to see the return working of the Branksome engineers train as it made a belated departure to Eastleigh East Yard – delayed by almost 30 minutes because of overrunning engineering work!
Following the completion of the work at Branksome, the engineering train moved up to Poole Storage Sidings. GBRf Class 66 No. 66730 ‘Whitemoor’ passes through Poole leading on 6G12 0430 Poole to Eastleigh East Yard with No. 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’. Departure of this train was delayed by, er. over-running engineering works – 25/03/2024
Video of GBRf Class 66 No.’s 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ and 66730 ‘Whitemoor’ working 6G12 0430 Poole to Eastleigh East Yard at Poole -25/03/2024
Tuesday 26th March 2024 saw further South Western Railway (SWR) Class 458 electric multiple unit (EMU) drags between Widnes Transport Tech and Bournemouth TRSMD taking place. Much excitement on the rail enthusiast grapevine when it was discovered that newly repainted GBRf Class 69 No. 69009 was allocated. This particular locomotive was released into traffic back in October 2023 still in its green primer coat, but has recently received a new paint job at Arlington Fleet Services located at Eastleigh Works, emerging in Class 52 “Western” style livery. This is inspired by the British Rail carriage maroon colours with half yellow warning panels and white window surrounds as carried by 71 of the 74 Class 52 “Western” Diesel-Hydraulic locomotives between 1962 and 1971.
GBRf Class 69 No. 69009 ‘Western Consort’ at Poole as part of the running around its train exercise whilst working 5Z66 2018 Bournemouth TRSMD to Eastleigh East Yard – 26/03/2024
The locomotive livery has been completed with the addition of cast number and ‘Western Consort’ name plates in classic “Western” Great Western Railway (GWR) serif lettering. The name was decided upon by GBRf CEO, John Smith, as the original ‘Western Consort’ (No. D1065) was his favourite member of the class.
We had intended on seeing the train at Branksome, but rush hour traffic queues meant this idea was abandoned, as was the alternative destination Parkstone. Instead, we were able to retrace our steps to Poole and pass the train as it sat in the station before moving out to Poole Storage Sidings where the locomotive would detach and run round before hauling the refurbished Class 458/4 back in the direction of Bournemouth depot.
GBRf Class 69 No. 69009 ‘Western Consort’ arrives at Poole Storage Sidings with Class 458/4 No. 458422 forming 5Q64 Southampton Down Loop to Bournemouth TRSMD- 26/03/2024GBRf Class 69 No. 69009 ‘Western Consort’ at Poole Storage Sidings with Class 458/4 No. 458422. The locomotive is about to detach from the train and will run into Poole station before returning and attaching to the London end of the consist – 26/03/2024GBRf Class 69 No. 69009 ‘Western Consort’ light engine at Sterte, Poole as she runs around her train – 26/03/2024
After watching the maroon Class 69 locomotive head off light engine from our vantage point on the footbridge above Poole Storage Sidings, we decided to move up to Poole railway station in order to watch the train being taken to its final destination once reunited with No. 69009. However, as we, and a few other enthusiasts, gathered under Towngate Bridge at the London end of the down platform to shelter from the rain, we were approached by an officious and extremely rude member of station staff, which for the purposes of this narrative we shall call Dave – because that’s his name – who informed us we were in contravention of the rules and too close to the platform edge. Everyone there was on the correct side of the yellow line, with the exception of the member of railway staff who took great pleasure in blocking our view of the approaching train. There was also nobody standing in the ambiguous hatched area located at the platform end, nor were we past the sign which clearly informs rail users they should not “pass this point”. In this H&S conscious modern era, I have always taken care to observe safety regulations and very much resent being spoken to like a child. I will not be including Dave on my Christmas card list.
GBRf Class 69 No. 69009 ‘Western Consort’ passing Poole working 5Q64 Southampton Down Loop to Bournemouth TRSMD – 26/03/2024GBRf Class 69 No. 69009 ‘Western Consort’ at Poole – 26/03/2024
Video of GBRf Class 69 No. 69009 ‘Western Consort’ on Class 458 unit drags – 26/03/2024
I’ve included a few images below of Class 52 “Western” locomotives in preservation which clearly show the inspiration for the livery carried by No. 69009 ‘Western Consort’.
D1015 ‘Western Champion’ is one of seven preserved Westerns from the original 74 built by BR at Swindon and Crewe. She is seen here at Eastleigh during a Works Open Day – 24/05/2019No. D1010 ‘Western Campaigner’ seen at Minehead on the West Somerset Railway (WSR) was built at BR Swindon Works in 1962 and withdrawn on 27/02/1977 at 1630 after completing 1,360,740 miles in BR service – 20/07/2013No. D1010 ‘Western Campaigner’ at Blue Anchor in the guise of No. D1035 ‘Western Yeoman’. Following withdrawal from BR, D1010 was sold to Foster Yeoman in July 1977 and moved to their base at Merehead Quarry. The loco was, at that point, repainted into BR Green livery with full yellow ends and was renamed ‘Western Yeoman’ carrying the number D1035 – 20/07/2013In January 1993, Foster Yeoman agreed to sell No.D1035 / D1010 to the Diesel and Electric Preservation Group (DEPG) who then replaced the ‘Foster Yeoman’ name and D1035 number with the original D1010 and ‘Western Campaigner’ plates and painted the loco into BR Blue with small yellow warning panels. No. 1035 ‘Western Campaigner’ is seen at Bishops Lydeard running as withdrawn classmate No. D1035 ‘Western Yeoman’ – 20/07/2013A young Yoshi on one of his first railway themed adventures admires Class 52 No. D1010 ‘Western Campaigner’ at Williton shed on the West Somerset Railway. The locomotive had failed at Bishops Lydeard in June 2018 with a seized transmission at the ‘B’ end. The loco was towed to Williton after disconnecting the cardan shaft on ‘B’ transmission. Work continues on fault diagnosis and repair with the hope she will return to service in 2025 – 21/06/2019Class 52 No. D1015 ‘Western Champion’ on the approach to Weymouth at the head of Pathfinder Tours “The Western Wessexman” 1Z52 0553 Leicester to Weymouth – 07/09/2013 (John Chappell)Class 52 No. D1015 ‘Western Champion’ at Weymouth having arrived with “The Western Wessexman” 1Z52 0553 Leicester to Weymouth rail tour – 07/09/2013 (John Chappell)
Returning to 2024, and the last special working which visited Dorset in March was Saphos Trains “The Golden Arrow” rail tour to Folkestone and Canterbury which was in the charge of Locomotive Services Limited (LSL) diesel engines; Class 47 No. 47810 (D1924) and Class 57 No. 57311. Later on in the rail tour schedule, outside of Dorset, the Class 57 was replaced by steam traction in the shape of LMS 4-6-0 Royal Scot Class No. 46100 ‘Royal Scot’. The steam locomotive was itself replaced by No. 57311 prior to the tour returning to Dorset metals. This return working operated as 1Z47 1559 Canterbury West to Poole, which arrived back at its final destination 20 minutes late at 0018 on the 31st March 2024 before forming the balancing Empty Coaching Stock (ECS) movement 5Z50 0004 Poole to Eastleigh Works BRML Head Quarters departing 19 minutes behind schedule at 0023 via Poole Storage Sidings. Yoshi and I were happily tucked up in bed at this point after our early start!
Locomotive Services Limited Class 47 No. 47810 (D1924) ‘Crewe Diesel Depot’ arrives at Poole leading on the Empty Coaching Stock movement Saphos Trains “Golden Arrow” reporting as 3Z45 0406 Eastleigh Works to Poole – 30/03/2024LSL Class 57 No. 57311 in lined black livery in readiness for departure from Poole hauling Saphos Trains “Golden Arrow” 1Z46 0553 Poole to Canterbury West – 30/03/2024
Video of Class 47 No. 47810 (D1924) and Class 57 No. 57311 at Poole – 30/03/2024
That brings us to the end of another blog entry. Thanks, as always, for reading, your comments and corrections. These are always welcome. Until next time, Be Seeing You!
Postscript
We ended March attending another gig at the O2 Academy where we nostalgically remembered years gone by in the company of Stereo MC’s, Inspiral Carpets and Happy Mondays as they brought “The Been There Done That” tour to Bournemouth – 31/03/2024
Freightliner Class 66 locomotives No.’s 66520 and 66512 at Bincombe during engineering work reporting as 6Y85 2348 Eastleigh East Yard to Dorchester South – 18/03/2024
March 16th 2024 to March 22nd 2024
Maintenance work between Dorchester and Weymouth closed the railway line from Monday 18th to Wednesday 20th March 2024 affecting both South Western Railway (SWR) and Great Western Railway (GWR) services along this route. In association with the work, an engineers train, in the hands of Freightliner, worked from Eastleigh East Yard to Dorchester South overnight of 16/17th March, arriving in the County Town at 0156 on the Monday morning, approximately 46 minutes behind schedule. We saw the train pass through Hamworthy, top and tailed by Class 66 locomotives No.’s 66520 and 66512, at which point it was running 36 minutes late.
Freightliner Class 66 No. 66520 leads through Hamworthy working 6Y85 2348 Eastleigh East Yard to Dorchester South – 17/03/2024FL Class 66 No. 66512 brings up the rear on 6Y85 2348 Eastleigh East Yard to Dorchester South passing Hamworthy – 17/03/2024
As we arrived at the station in good time to see the engineering train heading to Weymouth, we were surprised to see an empty coaching stock movement, formed of SWR Class 444 No. 444001 passing through Hamworthy just after 0100 on its way to Bournemouth Traincare depot working as 5W71 0041 Weymouth to Bournemouth TRSMD. A result of the line being closed in the Poole area on the Sunday meant trains from London Waterloo terminated at Bournemouth. A replacement bus service ran to stations between Bournemouth and Wareham with a shuttle train service operating between Wareham and Weymouth during the day.
The worksite necessitating the Monday to Wednesday line closure was located in the Bincombe area, where track would receive the attention of a tamper and gain some fresh ballast. We popped out on Monday afternoon to take a look at what was going on, expecting to find the two Class 66 locomotives parked up on the down line between Bincombe Tunnel and Bincombe Tunnel Number 2. Instead we found Quattro Group’s Mercedes rail road vehicle ‘Mad Vax’ and one of their tracked Road Rail Vehicles (RRV).
A RailRoad vehicle at Bincombe – 18/03/2024Quattro Group’s Mad Vax vacuum excavation system, which won the Most Innovative RRV Product Award at the National Rail Awards in 2019, prepares to do its stuff at Bincombe. Quattro Group are rightly proud of this piece of kit; “The Mad Vax vacuum excavation system has all the power and performance needed to complete a wide array of rail applications from ballast removal to spillage clean up operation. The unit’s spoil capacity is an impressive 6m3, and with a side tipping hopper it can be emptied lineside, utilising a special split-lid spoil tank to give a lower overall profile and to reduce overall tipping height for works under overhead power cables or at a suitable location when off track. The machine is also equipped with a Powerarm and IKE rotating suction tube to aid in breaking up harder ground for improved efficiency.” – 18/03/2024Bincombe worksite for the March 2024 maintenance work – 18/03/2024
After a quick chat with friend of this blog, Robin, we drove off towards Upwey to see if the engineers train was stabled near the railway station. Despite much of the line side trees and vegetation having been cut back, there was no sign of the Freightliner train. After refreshments at The Royal Standard in Upwey, we proceeded to drive back towards Dorchester when, glancing to the right as we came over the brow of Ridgeway hill, we could see the unmistakable sight of a Class 66 locomotive. Parking the car in the next lay-by, I crossed over the road and proceeded along the footpath back in the direction of Weymouth to see if it was possible to get a photo of the train at rest.
Class 66 No. 66512 stands out amidst the Dorset countryside – 18/03/2024
I was quite pleased with the resulting photo of the train parked at the northern portal of Bincombe Tunnel, perfectly placed for a photograph imho.
Because I liked the shot so much, another view of Freightliner Class 66 locomotives No.’s 66520 and 66512 at Bincombe during engineering work reporting as 6Y85 2348 Eastleigh East Yard to Dorchester South – 18/03/2024A tamper sits in the sidings at Dorchester South waiting to be deployed at Bincombe – 18/03/2024 (G E Barrett)
The Class 66’s returned to Eastleigh on the afternoon of Tuesday 19th March. It was quite a novelty to see a local engineers train working in daylight hours!
Class 66 No. 66512 awaiting departure with 6Y85 1454 Dorchester South to Eastleigh East Yard – 19/03/2024 (G E Barrett)Class 66 No. 66520 in the gloom of a wet Dorchester South at the rear of 6Y85 1454 Dorchester South to Eastleigh East Yard – 19/03/2024 (G E Barrett)Freightliner Class 66 No. 66512 ready to depart from Dorchester South working 6Y85 1454 Dorchester South to Eastleigh East Yard – 19/03/2024 (G E Barrett)Freightliner Class 66 No. 66512 leads on 6Y85 1454 Dorchester South to Eastleigh East Yard passing Hamworthy – 19/03/2024Freightliner Class 66 No. 66520 runs through Hamworthy at the rear of 6Y85 1454 Dorchester South to Eastleigh East Yard – 19/03/2024
Video of Freightliner Class 66 No.’s 66520 and 66512 working a Dorset engineering train – March 2024 (Additional video courtesy of G E Barrett)
The monthly New Measurement Train (NMT) which is scheduled to visit Weymouth via the West route through Maiden Newton was curtailed at Yeovil on Wednesday 20th March 2024 owing to the line closure between Dorchester and Weymouth. Allocated Class 43 High Speed Train (HST) power cars No.’s 43357 and 43277 worked 1Q18 0748 Derby RTC to Bristol Kingsland Road.
While the NMT was making its way to Somerset, I could be found at Norden on the Swanage Railway watching visiting South Eastern & Chatham Railway (SECR) Class O1 steam locomotive No. 65 being prepped for towing down to Swanage in readiness for the railways Victorian Weekend. Resident preserved Birmingham Rail & Carriage Works (BR&CW) Class 33 No. 33111 had the task of collecting No. 65 and hauling her down to Swanage.
Swanage resident Class 33/1 No. 33111 cautiously hauls South Eastern & Chatham Railway (SECR) Class O1 steam locomotive No. 65 away from Norden sidings – 20/03/2024South Eastern & Chatham Railway (SECR) Class O1 steam locomotive No. 65 at Norden during the operation to haul her to Swanage in readiness for the railway’s Victorian Weekend – 20/03/3024Class 33/1 No. 33111 hauls South Eastern & Chatham Railway (SECR) Class O1 steam locomotive No. 65 as they depart Norden station heading to Swanage – 20/03/2024
SECR O1 No. 65 arrives on the Swanage Railway – 20/03/2024
The following day, I hitched a lift with friend of the blog Jamie for a visit to Maiden Newton to see Colas Railfreight Class 37 No.’s 37175 and 37219 ‘Jonty Jarvis’ top and tailing a Structure Gauging Train on its way from Westbury to Weymouth and return. The working left Westbury around two hours late and I probably aged Jamie by a few years by claiming we had plenty of time to make the journey over to see the train! We arrived in Maiden Newton with ten minutes to spare.
Great Western Railway Class 166 No. 166210 on the approach to Maiden Newton working 2V68 1328 Weymouth to Gloucester – 21/03/2024Colas Railfreight Class 37 No. 37175 on the approach to Maiden Newton leading on 3Q14 1021 Westbury Down Yard to Westbury Down Yard – 21/03/2024Colas Railfreight Class 37 No. 37175 with 37219 ‘Jonty Jarvis’ at the rear at Maiden Newton leading on 3Q14 1021 Westbury Down Yard to Westbury Down Yard on the outward leg to Weymouth – 21/03/2024On the return leg of 3Q14 1021 Westbury Down Yard to Westbury Down Yard Colas Class 37 No. 37219 ‘Jonty Jarvis’ leads into Maiden Newton – 21/03/2024 Colas Class 37 No. 37219 ‘Jonty Jarvis’ pauses at Maiden Newton as the driver collects to token to allow the train to progress onto the next single line section of track – 21/03/2024Great Western Railway Class 166 Turbo’s cross at Maiden Newton; No.166220 working 2O76 1110 Gloucester to Weymouth and No. 166210 forms 2V68 1328 Weymouth to Gloucester – 21/03/2024
Maiden Newton trains – 21/03/2024
Later that night, another engineering train ventured into Dorset in conjunction with work in the Christchurch area. I didn’t see train 6N75 2300 Eastleigh East Yard to Christchurch arrive, but I did get up early Friday morning to see DB Class 66 No. 66118 and pioneer shed No. 66001 departing Bournemouth as they returned with their train to Eastleigh East Yard this time working as 6N75 0505 Bournemouth to Eastleigh East Yard. It was so early, Bournemouth railway station was still locked up when I arrived. However the train departed around 20 minutes behind schedule, but not wanting to risk missing filming the departure, I stood steadfastly at my vantage point overlooking the station when I could have easily ventured down to platform level once the station was opened up to the travelling public for the first passenger trains of the day.
With Bournemouth railway station as its backdrop, DB Cargo Class 66 No. 66118 awaits departure working 6N75 0505 Bournemouth to Eastleigh East Yard – 22/03/2024DB Cargo Class 66 No. 66118 at Bournemouth leading on 6N75 0505 Bournemouth to Eastleigh East Yard – 22/03/2024DB Cargo Class 66 No. 66001 at the rear of 6N75 0505 Bournemouth to Eastleigh East Yard – 22/03/2024DB Cargo Class 66 No. 66001 awaits departure of 6N75 0505 Bournemouth to Eastleigh East Yard – 22/03/2024
DB Cargo Class 66’s at Bournemouth – 22/03/2024
HAMWORTHY BRANCH
Poole Harbour Commissioners (PHC) Annual Stakeholders Open Evening 2024 – 20/03/2024
Poole Harbour Commissioners (PHC) Annual Stakeholders Open Evening 2024 took place on 20th March in the North Lounge of the Passenger Terminal. We went along to see if there were any updates on the restoration of freight traffic along the Hamworthy Branch which runs down to the port area from a junction to the mainline at Hamworthy railway station. PHC CEO Captain Brian Murphy said; “We are very fortunate to have the port railway. We haven’t used it for some time, but it’s there and it aligns perfectly with our decarbonisation goals. Modal shift is the best way to get transport off the roads. We want to grow the business, we want to grow the freight. We want more cargo through the port but we’d rather actually get as much as possible on to rail rather than the roads. So this does align with the governments ambitious targets which are of part of their 2050 plan for clean maritime and reducing carbon emissions and there has been a lot of work which has actually happened thus far. The commissioners have invested quite heavily in securing the lease that runs from the port all the way to the mainline and there has been a lot of upgrading work which has happened on the Hamworthy Branch. We’ve got a little bit more to do in terms of in the port but we are looking at the business case and hopefully it all aligns. But clearly in terms of ownership, it’ll be a lot of trucks off the road so very excited about that project.”
We recently learned of the passing of our friend and fellow railway enthusiast, Syd Brown. Syd has been a transport enthusiast for many years and could regularly be found supporting local transport events. He was an active member of the old Dorset Transport Circle in times past. Syd’s working life was spent in Dorset County Council’s Roads and Bridges department (now known as Transport and Engineering) and he was also an official in the Dorset County branch of NALGO (now UNISON). Our condolences to Syd’s family.
Thank you for reading and for your comments and corrections. We’ll be back soon with our record of our day attending the Swanage Railway Victorian Weekend. Be seeing you!
Postscript:
Will we ever see trains coming off the Hamworthy Branch again? Back in 2017, DB Cargo Class 60 No. 60054 heads towards the mainline at Hamworthy while South West Trains (SWT) Class 444 No. 444032 waits at platform with a Weymouth service – 17/02/2017 DB Cargo Class 60 No. 60054 draws up to the signal protecting the branch from the mainline at Hamworthy – 17/02/2017
Yoshi visited The London Museum of Water & Steam to celebrate the New Year. In the background are the museum buildings and the impressive Victorian standpipe tower, which is not, as you might expect, a chimney but a brick winter coat for the two systems of vertical pipes – through which water was pumped before it entered the mains water supply – contained within to prevent freezing and is the museum’s most striking feature standing at 200 ft high. The Grade I brick tower, of Italianate design, was constructed in 1867 to replace an earlier open metal lattice structure – 01/01/2024
January 1st 2024 to January 11th 2024
We kicked off 2024 with a visit to the “New Years Steam Up” being held at the London Museum of Water & Steam in Brentford. The Steam Up weekend of celebrations was the first opportunity in two years for people to marvel at the monstrous working steam engines that once provided water to the millions living and working in London. In July 2022, the Museum’s 96 year old Lancashire Boiler failed an inspection when it was discovered one of the seventeen rivets which hold the crown valve mounting flange onto the main boiler shell had lost its heat inside the boiler’s steam space. This meant that the boiler could no longer be used and the steam engines fell silent and still while extensive repairs were carried out. Now, just in time to celebrate the museum’s 50th anniversary the boiler is steaming once again.
Situated on the site of the former Kew Bridge Pumping Station, close to Kew Bridge on the River Thames in West London, the museum is centred on a collection of stationary water pumping steam engines dating from 1820 to 1910. It is the home of the world’s largest collection of working Cornish engines, including the largest working beam engine in the world; the Grand Junction 90 inch.
The Grand Junction 90 inch has a cylinder diameter of 90 inches (hence its name!) and was used to pump water to London for 98 years. This machine is over 40 feet high and weighs about 250 tons. It was described by Charles Dickens as “a monster”. It was built by Sandys, Carne & Vivian of Hayle in 1846 as the first Cornish beam engine specifically designed for water supplies and was powerful enough to supply water to the upper floors of buildings, allowing direct supply to upstairs bathrooms 01/01/2024
We arrived early after a good run in the car up from Dorset and luckily found parking on site in the small car park at the museum, although the site is only a 3 minute walk from Kew Bridge railway station if you chose to arrive by train. There were a number of families in evidence with young children during our visit and the museum is a great place to learn and have fun.
Exhibiting a plethora of steam, diesel and electric powered pumps, the London Museum of Water & Steam tells the story of London’s water supply housed in historic Georgian buildings and they very kindly allowed access to Yoshi, but explained that our boy may not like some of the steam engines when they are working. We duly followed this advice and Yoshi waited with one of his hoomans in the Pump and Grind Coffee Shop or explored the garden area while the machines were being operated. The coffee shop was very busy and served an excellent cuppa. It is run by “Our Barn Community”, a local charity working with young people with learning difficulties enabling a supported work placement.
We have shared just a small fraction of the engineering marvels housed at the museum below:
The Waddon Engine with drove 3 pumps was built by James Simpson & Co of Newarkin 1910 and originally found use at Waddon Pumping Station in Croydon. It was the last steam water-pumping engine in active UK service before being retired in June 1983. It was restored in 1990 and restored to original Edwardian colours for display at the museum – 01/01/2024This waterwheel was built in 1902 by S. Hindley & Sons in Bourton, Dorset for the Duke of Somerset to serve his estate at Maiden Bradley in Wiltshire and was one of the last waterwheels ever built to pump water in the UK – 01/01/2024The Boulton & Watt (West engine) is the oldest engine in the London Museum of Water & Steam having been built in Birmingham in 1820.It was one of a pair moved to Kew in 1840 which were then converted into a Cornish type between 1846 and 1848. Retired in 1944, this was the first engine to be returned to working order in 1975 – 01/01/2024
Kew Bridge Pumping Station was originally opened in 1838 by the Grand Junction Waterworks Company, expanding over the ensuing years and ultimately housing six steam pumping engines as well as four Allen diesel pumps and four electric pump sets. The steam engines were retired from service in 1944, although two were kept on standby until 1958. The Metropolitan Water Board thankfully decided not to scrap the resident steam pumping engines and set them aside to form the basis of a museum display at a later date which came to fruition in 1974 with the formation of the Kew Bridge Engines Trust.
The original Number 1 horizontal AC motor driving centrifugal pump was built in 1944 by Hawthorn Davey & Co of Leeds. This type of electric pump replaced steam engines at pumping stations across the UK and this example is the oldest surviving pump of its kind. It was retired in the late 1980’s – 01/01/2024
The museum also runs a 2 ft narrow gauge railway, which despite being advertised as running over the weekend, was unfortunately not operating during our visit. The museum has been a filming location for many television programmes, including the Doctor Who serial “Remembrance of the Daleks” broadcast in 1988.
After our visit to the London Museum of Water & Steam, we had planned on taking a trip into central London by rail, but in the event decided against this and instead took a drive and a leisurely walk around nearby Richmond, including a visit to the railway station. Of course we did!
The Art Deco façade of Richmond railway station complete with its square clock centrepiece – 01/01/2024
The Art Deco station building in Richmond, designed by James Robb Scott (1882-1965) for the Southern Railway and constructed in Portland stone dates from 1937 and replaced an earlier station on the site. Scottish born Scott became the Chief Architect of the Southern Railway and is perhaps best known for his redesign of London Waterloo between 1910 and 1923 where he was chiefly responsible for the offices, main entrance and war memorial to the fallen employees of the railway known as the Victory Arch. Scott also designed Wimbledon and Surbiton railway stations – now part of the South Western Railway (SWR) network – the latter having recently celebrated 40 years since being bestowed Grade II listed status.
SWR, Network Rail (NR) and the Railway Heritage Trust are jointly funding a £325,000 programme of improvements with hopes of more refurbishment to come in the future, subject to additional funding being made available. Initial work includes cleaning the Portland stone façade, repairing the timber entrance doors and polishing its bronze embellishments, repairing flagpoles and refurbishing customer toilets.
The restored entrance doors to Richmond railway station which Yoshi unceremoniously christened on our visit…. 01/01/2024
The style of the building at Richmond is suggested as being inspired by the work of Charles Holden (1875-1960), the architect behind London Underground stations including South Wimbledon on the Northern line. Holden’s designs included multi-frame glazing, enamelled signage panels, the use of an iconic typeface for signage and brick and tile detailing. Similar features at Richmond have been lost or covered up over time, including during the station’s last major refurbishment in 1985. SWR, NR and the Railway Heritage Trust have worked with Benedict O’Looney Architects on designs that include restoring or replicating those features, and others, in future improvements. Paying close attention to detail, the station’s original, hand-drawn plans are being used together with promotional photographs from when the station first opened its doors to customers. Samples of the station’s original paint are also being analysed by the University of Lincoln, specialists in the conservation and restoration of the interior and exterior features of listed and historic buildings.
The area in front of Richmond station main entrance was pedestrianised in 2013 and includes a war memorial to soldier Bernard Freyberg, who was born in Richmond. As well as Sir trains, the station is served by the London Overground North London Line and Underground District Line trains.
Star of the show, Adams 4-4-0 T3 No. 563 working the 1200 Swanage to Norden service approaches Corfe Common – 06/01/2024
The Swanage Railway’s first event of 2024 was their annual “Winter Warm Up” weekend held on January 6th & 7th. With cold, but clear weather forecast, I decided on heading down to Swanage on the Saturday after taking a chance on a picturesque sunrise at Durdle Door on the way.
Resident Class 33 No. 33111 crosses Corfe Viaduct hauling the 1245 Swanage to Norden train – 06/01/2023SR West Country 4-6-2 No. 34028 ‘Eddystone’ takes her turn on the demonstration freight working the 1132 Norden to Swanage nearing Afflington. Later during the weekend, brake van rides were offered – 06/01/2024This time working a passenger train, SR West Country 4-6-2 No. 34028 ‘Eddystone’ has departed Norden with the 1415 service to Swanage – 06/01/2024Class 33 No.D6515 ‘Lt Jenny Lewis RN’ takes her turn on the freight wagons working 1302 Norden to Swanage – 06/01/2024Class 33 No.D6515 ‘Lt Jenny Lewis RN’ departs Harman’s Cross with the 1030 Norden to Swanage – 06/01/2024
In action this year was the recently restored Adams 4-4-0 T3 No. 563 hauling its first freight train since its return to service, SR West Country 4-6-2 No. 34028 ‘Eddystone’ and the resident Class 33 diesel locomotives no.’s 33111 and D6515 ‘Lt Jenny Lewis RN’
Adams 4-4-0 T3 No. 563 powers away from Corfe Castle at the head of the 1357 Swanage to Norden demonstration freight – 06/01/2024
The Swanage Railway Trust 563 Locomotive Group have been nominated for the “Steam Railway Magazine Award”. This award is decided by the public and will be announced at Heritage Railway Association’s annual ceremony on February 10th 2024 and you can now cast your vote online until the 18th January 2024: www.steamrailway.co.uk/read/hra-awards
Video from January 6th 2024 Swanage Winter Warm Up
Scheduled mainline action kicked off the year with a “no-show” as the HST powered New Measurement Train (NMT) failed to reach Weymouth on January 3rd after a points failure at Castle Cary curtailed 1Z22 1211 Derby RTC (Network Rail) to Bristol Kingsland Road – top and tailed by Class 43 power cars No.’s 43274 and 43257 – at Westbury. Interestingly three different paths were put in for this test train on this particular day. The one which finally ran was timed later than the usual working to Dorset, but not as late as one of the options given for the day!
We did, however, get to experience a daylight Snow & Ice treatment Train (SITT) on Sunday 7th January as GBRf Class 66 locomotives No.’s 66764 ‘Major John Poyntz Engineer & Railwayman’ and 66772 ‘Maria’ in top and tail formation worked to Weymouth as 3Y88 1035 Totton Yard to Totton Yard. 66764 replaced No. 66723 ‘Chinook’ and No. 66743 which had both been previously paired up with No. 66772 on the Totton based SITT locomotive diagram.
Sunday morning tranquility is disturbed as GBRf Class 66 locomotives No.’s 66764 ‘Major John Poyntz Engineer & Railwayman’ and 66772 ‘Maria’ top and tail SITT 3Y88 1035 Totton Yard to Totton Yard across Upton Viaduct on the Holes Bay causeway – 07/01/2024GBRf Class 66 No. 66772 ‘Maria’ leads on the return 3Y88 1035 Totton Yard to Totton Yard Snow & Ice Treatment Train through Hamworthy with No. 66764 ‘Major John Poyntz Engineer & Railwayman’ at the rear – 07/01/2024GBRf Class 66 locomotives No.’s 66764 ‘Major John Poyntz Engineer & Railwayman’ and 66772 ‘Maria’ at Hamworthy working 3Y88 1035 Totton Yard to Totton Yard – 07/01/2024
Major John Poyntz served in the British army for 35 years, with the Royal Engineers and later the Royal Corps of Transport. After military service, he joined the Railway Inspectorate, now part of the Office of Rail and Road, and was the last Royal Engineer to take such a route, spending 25 years in the role as a Railway Inspector. His work included inspections of heritage railways and dealing with accidents and incidents such as the Severn Tunnel rail accident and the Cannon Street rail crash, both in 1991.
Overnight on Saturday 6th/Sunday 7th a ballast train headed to Moreton working as 6C03 2312 Eastleigh East Yard to Moreton (Dorset) in the hands of Colas locomotives Class 66 No. 66848 and Class 70 No. 70809. We saw the ensemble pass through Hamworthy on the outward leg and had planned to see the associated return 6C03 0810 Moreton (Dorset) to Eastleigh East Yard crossing Holes Bay, but as the train set off over an hour early and with the sun yet to rise, we played safe and returned once again to Hamworthy railway station to watch the train pass through.
January ballast train with Class 66 No. 66848 and Class 70 No. 70809
The SITT returned to the Bournemouth to Weymouth line under the cover of darkness on Monday 8th and Wednesday 10th January employing the same pair of Class 66’s as the previous Sunday run.
January 2024 Dorset Snow & Ice Treatment Train workings (additional video courtesy of G E Barrett)
In between the SITT workings, on Tuesday 9th January, we saw a first for Dorset as Direct Rail Services (DRS) ran a service to Winfrith using a Class 88 locomotive No. 88002 ‘Prometheus’ which had replaced failed Class 68 No. 68004 (which itself had substituted for No. 68005) and No. 68003 ‘Astute’ in top an tail formation. This was the inaugural use a Class 88 on the Bournemouth to Weymouth line.
DRS Class 68 No. 68003 ‘Astute’ with Class 88 No. 88002 ‘Prometheus’ working the empties to Winfrith as 6Z62 0100 Crewe Coal Sidings (DRS) to Winfrith Sidings through Hamworthy – 09/01/2024DRS Class 68 No. 68003 ‘Astute’ leads the return 6Z95 1551 Winfrith Sdgs to Crewe Coal Sidings (DRS) at Hamworthy – 09/01/2024Class 88 No. 88002 ‘Prometheus’ at the rear of 6Z62 0100 Crewe Coal Sidings (DRS) to Winfrith Sidings having cleared Hamworthy railway station. Class 68 No. 68003 ‘Astute’ leads – 09/01/2024
The Class 88 is a mixed traffic electro-diesel locomotive manufactured by Stadler Rail and is part of the Stadler Euro Dual family.
Class 88 No. 88002 ‘Prometheus’ remained at the rear for the return 6Z95 1551 Winfrith Sidings to Crewe Coal Sidings (DRS) – 09/01/2024
During the development of the Class 68 diesel locomotive for DRS which was first announced in January 2012, the design team at Stadler proposed the concept of a dual-mode locomotive that could be alternatively powered by an onboard diesel engine or via electricity supplied from overhead lines (OHLE). In comparison to conventional diesel locomotives, this arrangement enables operational costs to be significantly reduced when diagrammed on routes partially or entirely under OHLE, under which the diesel engine can be deactivated.In September 2013, DRS placed an order for ten such locomitives which would become the Class 88. Having been developed alongside the Class 68, considerable similarities are shared between the two locomotive types, with an approximate 70% share of components.
Video of January 9th 2024 Winfrith run (additional video courtesy of G E Barrett)
The Class 88 is the first dual-mode locomotive type in the UK to use the 25 kV AC electrification, as the only other electro-diesel locomotives to have entered service with British Railways are the Class 73’s and Class 74’s, which operated on the Southern Region using third rail electrification, and we’ve reached back into the archives to find some images to share:
Class 74 No. 74010 at Doncaster Works. Withdrawn from service in December 1977, the locomotive was cut up here in October 1979 after being given a brief reprieve so that it could be for evaluated for departmental use by the Railway Technical Centre (RTC) in Derby. It was given a light overhaul at Eastleigh before being towed to Derby, where it was eventually deemed to be unsuitable and taken to Doncaster for scrapping – 22/07/1979A hastily taken photo of Class 74’s at London Waterloo taken from a departing train bound for Weymouth. This side of the station later became Waterloo International between 1994 and 2007 – July 1977Class 74 No. 74004 has had a bit of a bump (not helped by my camera shake!) as it stands forlorn at Eastleigh Diesel Depot during the 1978 Open Day. This locomotive was withdrawn from service in December 1977 and cut up at Birds in Long Marston. She was originally built as the pioneer Class 71 and numbered E5000 – 30/04/1978Withdrawn Class 74’s at Eastleigh Diesel Depot Open Day including No.’s 74005 and 74009 – 30/04/1978
Eastleigh Open Day 1978 flyerClass 73 No. 73122 and 2-HAP Unit No. 6103 with a third unidentified carriage and Class 33 No. 33116 working a test train towards Dorchester South – 13/05/1981The same test train as in the image above focussing on Class 33 No. 33116 on the approach to Dorchester South – 13/05/1981
For The Record:
In other news, the SWR Class 701 Electric Multiple Units (EMU’s) finally entered revenue earning service on Tuesday 9th January 2024 when No. 701037 worked a single round trip between Waterloo and Windsor Eton Riverside. The Derby-built trains had been due to enter service in 2019. SWR have since promised the rolling stock would enter passenger service in 2023 – a promise echoed by the Department for Transport (DaFT) in a statement issued in May 2023, which said the trains would run “this calendar year”. It is intended a Class 701 will continue to run off-peak Monday to Friday between London Waterloo and Windsor, in order to fulfil that commitment, making one single round trip each day, or working between 1000 and 1600. The phased entry into service of the Class 701’s – which continue test runs to Poole and Bournemouth – will eventually allow for the withdrawal of SWR’s Class 455 units and the cascade of the Class 458 fleet to longer distance services.
Back in 2020, the first Class 701 to be delivered, No. 701002, was delivered to South Western Railway and somehow made its way to Weymouth where it is seen here in Jersey Sidings awaiting commissioning tests. Yoshi and I stumbled across it while out for our morning walkies – 16/06/200
The North Dorset NMT ran on Thursday 11th January 2024 – a week earlier than I expected – in the hands of HST Class 43 power cars No.’s 43013 and 43257.
Lake Road was closed to road traffic from its junction with Lake Drive to its junction with Coles Avenue from Monday 8th January up to and including Friday 12th January 2024 – 2200 to 0600 daily to facilitate removal of material from a bridge strike and replace missing signage on Lake Road Bridge situated on the Hamworthy Branch. We popped by a couple of times, and although the road was indeed closed, there didn’t seem to be any activity taking place with regards to bridge repairs, which is disappointing to say the least.
Road closure at Lake Road bridge – but little sign of any repairs taking place – 08/01/2024Yoshi had his first grooming session of 2024 on Monday 8th January and couldn’t wait to show off his new cut to his grandmama – 08/01/2024
That brings us to the end of another blog entry. Next week, we’ll celebrate Yoshi’s birthday and hopefully have some more Dorset based railway images and video to bring you. Thank you for reading and for your comments, corrections and amendments. All very much appreciated. We’ll leave you with a couple of shots from that early morning trip to Durdle Door! Be seeing you!
Sunrise at Durdle Door – 06/01/2024Sunrise at Durdle Door – 06/01/2024
Yoshi visited STEAM: The Museum of the Great Western Railway and saw GWR King Class 4-6-0 No. 6000 ‘King George V’ – 11/11/2023
November 10th 2023 to November 17th 2023
Having not seen any of the locomotive operated Rail Head Treatment Trains (RHTT) this year, we decided to combine a visit to the McArthur Glen Designer Outlet in Swindon with a visit to STEAM Museum and the chance of photographing an RHTT or two. The railways of Dorset are serviced by Multi Purpose Vehicles (MPV) during leaf fall season with leaves on the railway line causing problems.
An early morning MPV RHTT working crosses Upton Viaduct on the Holes Bay Causeway, Poole as 3S81 0547 Totton Yard to Totton Yard – 07/11/2023
Windy conditions can cause heavy leaf fall in a short space of time and rain means they are more likely to stick to the rails. When trains pass over leaves, the heat and weight of the trains bake them into a thin, slippery layer on the rail. This is equivalent to black ice on the roads. This can create operational issues for the signalling system (track circuits) and reduce a trains grip – which can change the ability of a train to start from a station, accelerate and climb hills, or stop at stations and signals. Across the GB Rail Network, there are 32 MultiPurpose Vehicles and 29 locomotive hauled RHTT’s. Both types of train are equipped with a high-pressure water pump delivering 1,500 Bar and, if required, can apply adhesion modifier – a mixture of suspension gel (so it can be pumped), sand (to help train wheels grip the rail), and steel or iron shot that is pushed through contamination (compressed leaves and debris) on the rail head to help the track circuits work correctly – to each running rail. If the track circuits fail to identify, or ‘lose’ a train (because the leaf and debris contamination is preventing this) then the signalling system is designed to automatically stop all the trains to prevent an accident.
Colas Class 66 No.’s 66848 & 66850 ‘David Maidment OBE www.railwaychildren.org.uk’ on the approach to Swindon working 3S59 09:00 Hereford to Swindon Transfer Yard Rail Head Treatment Train – 11/11/2023
Swindon has been synonymous with railways, and in particular the Great Western Railway (GWR) since the 1840’s, when Daniel Gooch – working under Isambard Kingdom Brunel – picked the Wiltshire town as the location for a central repair works with the site opening on 2nd January 1843. The Works transformed Swindon from a small market town with a population of 2,500 into a bustling railway themed hive of industry. Built to the north of the main town centre, Swindon works had a need for locally accessible housing and services for the men and women who worked there. The development of the railway village was on the lines of similar Victorian-era model village lifestyle concepts, such as Bournville near Birmingham, and architect/builder Rigby’s were given license to create a commercially viable development by the GWR. The completed village provided the town with medical and educational facilities that had been previously sorely lacking, together with the large St Mark’s Church and the Bakers Arms public house, all completed before 1850.
The first locomotive constructed at Swindon Works, emerging in 1846 having taken less than two weeks to build, was the ‘Premier’, originally built with a 2-2-2 wheel arrangement but later converted to 4-2-2 and renamed ‘Great Western’ becoming part of the Iron Duke Class of broad gauge locomotives. She was joined by six more engines, with the Iron Dukes being considered the fastest broad gauge engine of its day. By 1851, the works employed over 2,000 people and were producing about one locomotive a week, with the first standard gauge engine being built in 1855. In addition to locomotive building standardised goods vehicles were produced, and in 1867 Swindon was made the central workshop for the construction of carriages and wagons.
In its heyday, Swindon works employed 14,000 people as Charles Collett (GWR’s Chief Mechanical Engineer from 1921 to 1941) greatly improved boiler making and facilities for working heavy gauge sheet metal. In 1927 the GWR’s most powerful and largest class of locomotive, the King’s, were introduced becoming the flagship of the GWR fleet. The King’s had been developed from the Castle Class which, along with the Hall Class, helped cement GWR’s reputation and image.
At the nationalisation of British Railways (BR) in 1948, the works was producing 60 new locomotives a year, with this number reducing to 42 in 1954. From 1948 to 1956, the works made 452 steam engines to GWR designs and between 1951 and 1960 200 BR standard classes. When the decision was made to transition the railways from steam to diesel and electric motive power, the works produced BR’s last steam locomotive; No. 92220 ‘Evening Star’. By this time the works employed 5,000 people and had become the regional hub for the storage and scrapping of steam locomotives and rolling stock.
BR Standard Class 9F 2-10-0 No. 92220 ‘Evening Star’ at the National Railway Museum, York 03/07/2012Nameplate and commemorative plaque commemorating No. 92220’s status as the final steam locomotive built for BR at Swindon – 03/07/2012
As part of its Modernisation Plan, BR Western Region opted to develop and build diesel hydraulic locomotives rather than the diesel electric varieties employed across the rest of the network. From 1957 the works produced 38 “Warship” class D800’s and 30 “Western” class D1000’s.
Class 42 Warship Diesel Hydraulic No. D818 ‘Glory’ at Swindon Works. This locomotive entered traffic on 30th March 1960 and was withdrawn on 1st November 1972. She was cut up in November 1985. ‘Glory’ was a static exhibit at Swindon longer than she was in revenue earning service. Although No. D818 donated much needed parts to fellow classmate No. D821 ‘Greyhound’, it is still sad that this third candidate for preservation was lost – 06/06/1981Class 52 Western Diesel Hydraulic No. D1023 ‘Western Fusilier’ at Swindon where she had been built in September 1963. She was withdrawn in February 1977 having operated various runs including the last ever Western hauled rail tour; the ‘Western Tribute’. In 1973 she was the last ever hydraulic to have a general repair at Swindon. The locomotive was preserved as part of The National Collection and placed on display in the National Railway Museum at York in 1977. No. D1023 has been placed on loan to the Didcot Railway Centre for a period of five years commencing January 2023 – 06/06/1981Class 14 0-6-0 650hp diesel hydraulic No. D9551 in non-original ‘golden ochre’ livery at Kidderminster on the Severn Valley Railway. 56 of these locomotives were built by BR’s Swindon Works between 1964 and 1965. Locomotives of the class were given the nickname “Teddy Bears”, after a comment by Swindon Works foreman George Cole, “We’ve built the Great Bear, now we’re going to build a Teddy Bear!” – 15/05/2021
Locomotive building ceased at Swindon in 1965 following the construction of the Class 14 “Teddy Bear’s” after which the works became a heavy repair facility. In the 1970’s it was decided that the diesel hydraulic’s were non-standard and were withdrawn in favour of the diesel electric classes. The works were absorbed into British Rail Engineering Ltd (BREL) but won less and less maintenance business against the internal competition of Crewe and Derby Works. With the town of Swindon expanding and needing land close to its centre for development, the decision was made to close the works with the final day of operation being 26nd March 1986.
The redevelopment of the works took account of the listed building status of the original core infrastructure. The engineers’ office is now the headquarters of English Heritage, with most of the remaining buildings redeveloped as part of the Designer Outlet Village. The rest of the site’s extensive railway yard was used for housing and commercial buildings including purpose built storage for the English Heritage Archive and the National Trust’s central office building, known as “Heelis”, the married name of Beatrix Potter, one of the key figures in the early history of the organisation.
Another original works building houses STEAM: The Museum of the Great Western Railway, which “tells the story of the men and women who built, operated and travelled on the GWR, a network that, through the pioneering vision and genius of Isambard Kingdom Brunel, set the standard for rail travel. The story is brought to life with famous GWR locomotives, story-telling displays, videos – mixing rare archive film footage with the stories of ex-railway workers – hands-on exhibits, interactive displays and a large number of rare GWR objects and memorabilia.”
The folk at STEAM had very kindly given Yoshi permission to accompany me on my visit to the museum and we are very grateful for the team in extending the hand of friendship and being very helpful during our time there, which coincided with the National Trust’s AGM being held at the venue, so everyone was already very busy indeed.
King Class 4-6-0 No 6000 ‘King George V‘
GWR King Class 4-6-0 No. 6000 ‘King George V’ on display at STEAM 11/11/2023
Charles Collett, Chief Mechanical Engineer at Swindon Works 1922 – 1941, designed the King Class to be the most powerful express passenger steam locomotive in Britain.
In 1927, King George V was the first of the King locomotives to be built. The engine was named after the reigning monarch and later locos were named after previous kings of England.
The King locos were much heavier than previous engines. A number of bridges and platforms had to be strengthened to accommodate them. The Kings weren’t used in Cornwall because the Royal Albert Bridge was too weak to support their weight.
In 1927, No. 6000 ‘King George V’ was sent to the USA to take part in the centenary celebrations for the Baltimore and Ohio Railroad. While there, it was presented with the brass bell which is still attached to the front of the locomotive.
In 1947, the GWR began experiments leading to a number of modifications to ensure the King locomotives continued to perform well. By the time ‘King George V’ was retired in 1962, it had travelled nearly two million miles. But this wasn’t the end of the story as No. 6000 was preserved as part of the national collection and restored to main line running order at the Bulmer’s Railway Centre in Hereford. In 1971 ‘KGV’ became the first steam locomotive to break the British Rail mainline steam ban that had been in place since the completion of the “Fifteen Guinea Special” – the last main line passenger train to be hauled by steam locomotives over BR metals on 11th August 1968. No. 6000’s restoration to main line service and subsequent operation is often credited with opening the door for the return of steam to the mainlines of the UK.
Back in the 1980’s when I could afford to travel on steam hauled excursion trains, “run-pasts” were a feature where passengers would de-train and the locomotive would back up the stock and then go hell for leather through the station to enable travellers to get photographs of the steam locomotive as here with No. 6000 ‘King George V’ at Craven Arms during a “Welsh Marshes Pullman” tour – 21/11/1981GWR King Class 4-6-0 No. 6000 ‘King George V’ at Shrewsbury – 21/11/1981GWR King Class 4-6-0 No. 6000 ‘King George V arrives at Bristol Temple Meads at the head of “The Brunel Pullman” – 12/06/1983GWR King Class 4-6-0 No. 6000 ‘King George V’ pauses under the Royal Mail conveyor which was situated at the northern end of Bristol Temple Meads railway station. Built in the 1970’s to convey mail to the sorting office situated adjacent to the eastern edge of the station, use of the conveyor was stopped after closure of the sorting office on the transfer of Royal Mail’s activities to the West of England Mail Centre at Filton. It has now been removed – 12/06/1983GWR King Class 4-6-0 No. 6000 ‘King George V’ at Bristol Bath Road diesel depot – 12/06/1983GWR King Class 4-6-0 No. 6000 ‘King George V’ runs light engine through Bristol Temple Meads – 12/06/1983
2800 Class 2-8-0 No 2818
No. 2818 was built at Swindon Works in 1905 and has bee resident at STEAM since 2018 – 11/11/2023
George Jackson Churchward, Chief Mechanical Engineer at Swindon Works 1902 – 1921, designed the 2800 class of heavy freight locos – a completely new design and not based on any previous loco type. Churchward’s design proved to be so successful that they were built from 1903 until 1942. During the 60 years that they were in service, they only underwent minor changes to their original build.
The original paint livery was black with red lining. This was changed to green during the First World War. Once the locomotive was under British Railways ownership, it was given the standard unlined black livery.
No. 2818 was allocated to work in South Wales where she hauled heavy coal trains. During the First World War, the loco, along with most others in the class, hauled the Jellicoe Specials, transporting coal to the Royal Navy’s fleet of ships based in Scapa Flow. Unusually for freight locos, the 2800’s were also used on Bank Holiday passenger special trains, where they demonstrated both their strength and their speed.
City Class 4-4-0 No 3717 ‘City of Truro‘
Yoshi meest ‘City of Truro’ at STEAM – 11/11/2023
George Jackson Churchward also designed the City Class of locomotive. For the City locos, he used initial designs prepared by his predecessor, William Dean. The GWR built ten City Class locomotives between 1903 and 1907. They also converted ten GWR Atbara Class locos into the City Class.
‘City of Truro’ nameplate – 11/11/2023City Class 4-4-0 No 3717 ‘City of Truro’ at STEAM, Swindon – 11/11/2023
In 1903, No. 3440 ‘City of Truro’ became the 2,000th loco built at Swindon Works. She was re-numbered No. 3717 by GWR in 1912. This meant that locos of the same class all had consecutive numbers.
On 9th May 1904, ‘City of Truro’ laid claim at being the first steam locomotive to reach over 100 miles an hour. She was travelling between Plymouth and London Paddington, hauling the “Ocean Mails” consisting of a light load of 8-wheeled parcels vans with 1,300 bags of mail onboard giving a total weight of 148 tonnes. ‘City of Truro’ was timed as taking 8.8 seconds to travel a quarter of a mile; equal to 102.3 miles an hour. This was while descending Whiteball in Somerset and can only ever be a claim. It was recorded by railway journalist Charles Rous-Marten, but there was no second timekeeper to confirm his reading. ‘City of Truro’s record has therefore always been a matter of dispute, however if Rous-Marten’s timings are accurate they would indeed correspond to a speed of 102.3mph.
No. 3440 ‘City of Truro’ in readiness to work the RCTS “North Somerset Rail Tour” – 28/04/1957 (Photo courtesy of Chris Bancroft)No. 3440 ‘City of Truro’ at Reading on the RCTS “North Somerset Rail Tour”. This tour was the first one for the RCTS that used ‘City of Truro’- 28/04/1957 (Photo courtesy of Chris Bancroft)Video screen grab of No. 3440 ‘City of Truro’ working the return leg of Pathfinders Tours “The Ocean Mail 100” celebrating the oft disputed record run of 9th May 1904 when Charles Rous-Marten claimed the locomotive exceeded 100mph. The loco is seen on the Exeter to Taunton section of the GW main line on which the controversial speed record was recorded – 10/05/2004
Video of No. 3440 ‘City of Truro’ working the return leg of Pathfinders Tours “The Ocean Mail 100”. Ian Riley Engineering Ltd Electric owned Type Three Class 37/0 No. 37197 diesel-electric followed the steam hauled train ready to provide support if required – 10/05/2004
City of Truro was withdrawn from service in 1931. Although she was later returned to heritage railway service and continued operating until 2011.
Castle Class 4-6-0 No 4073 ‘Caerphilly Castle‘
Yoshi poses with Castle Class 4-6-0 No 4073 ‘Caerphilly Castle’. The Castle Class celebrate their centenary in 2023 – 11/11/2023
Charles Collett, Chief Mechanical Engineer at Swindon Works 1922 – 1941, designed the Castle Class of locomotive. He based the designs for the Castle Class locos on the earlier Star Class.
Who built, Castle class loconotives were Britain’s most powerful express passenger loco. Castle Class locos had larger boilers, and were designed to pull heavier loads.
Nameplate of Castle Class 4-6-0 No 4073 ‘Caerphilly Castle’ – 11/11/2023
Between 1923 and 1950, the GWR built 155 Castle locos at Swindon Works. A further sixteen were converted from other classes. On the 23rd August 1923, No. 4073 ‘Caerphilly Castle’ was the first Castle Class loco to go into service. In 1924 and 1925, ‘Caerphilly Castle’ was exhibited at the British Empire Exhibition at Wembley next to the LNER’s ‘Flying Scotsman’ ( a locomotive we may have mentioned more than once previously).
Visitors to STEAM can see underneath Castle Class 4-6-0 No 4073 ‘Caerphilly Castle’. Yoshi and I declined to take this opportunity – 11/11/2023
Castle Class locos were used on the express route between London Paddington and Cheltenham Spa. The Cheltenham Spa Express was a record breaker. In June 1923, it took just 75 minutes to travel from Swindon to Paddington, at an average speed of 61.8 miles per hour.
In July 1929, it became the world’s fastest train when it achieved an average speed of 66.2mph. On June 6th 1932, the Cheltenham Flyer smashed its own speed record, reaching an average speed of 81.6mph.
Replica of broad gauge engine ‘North Star‘
Yoshi with the replica of broad gauge engine ‘North Star’ – 11/11/2023
North Star is a broad gauge locomotive, built in 1837 for the New Orleans and Carrollton Railroad in the USA by Robert Stephenson and Company.
Replica of broad gauge engine ‘North Star’Replica of broad gauge engine ‘North Star’
The full size replica on display at STEAM was built at Swindon Works in 1926 to the 1837 specification. It was built to celebrate 100 years of the railways. The replica uses some parts from the original locomotive.
2301 Class 0-6-0 No 2516 Dean Goods
2301 Class 0-6-0 No 2516 Dean Goods – 11/11/2023
William Dean, Chief Locomotive Engineer at Swindon Works 1877 – 1902, designed the Dean Goods Class of locomotives. The first locomotive of the class was built in 1883 at Swindon.
During the First World War, 62 of these locos were sent to France and Salonika (Greece). The engines were lightweight, strong, and reliable, making them ideal for war work. Inexperienced crews also found them easy to drive. During the Second World War, 108 of these locos were requisitioned. Of these, 32 had already seen service during the First World War. Most were sent to France and many were destroyed in the retreat to Dunkirk or used on the French railways by German forces.
No. 2516 was built in 1897. It spent most of its working life taking goods and passengers up and down the GWR branch lines in Mid-Wales before being withdrawn from service in the 1950’s.
9400 Class 0-6-0T No 9400 Pannier Tank
9400 Class 0-6-0T No 9400 Pannier Tank on display at STEAM – 11/11/2023
Frederick Hawksworth designed the Pannier Tank Locomotives. Hawksworth spent his entire career at Swindon Works. He began as an apprentice in 1905 and rose to become Chief Mechanical Engineer in 1941, before retiring in 1949.
From 1947, GWR built ten Hawksworth Pannier Tan locos at Swindon Works. The loco was called a ‘Pannier Tank’ because the water tanks on either side of the boiler looked like pannier bags carried by horses.
Hawksworth Pannier Tank locos were used all over the rail network for shunting and hauling passenger and goods trains on smaller branch lines. The locos could often be seen taking empty carriages to and from Paddington Station.
In 1947, No 9400 was the first Hawksworth Pannier Tank to be built at Swindon. It was one of the last locos to be built by the GWR before the railways were nationalised in 1948. After nationalisation, private contractors for British Railways built another 200 Hawksworth Pannier Tanks. By 1965, all Hawksworth Pannier Tanks including No. 9400 had been withdrawn from service.
4200 Class 2-8-0T 4248 (skeleton only)
Diorama featuring 4200 Class 2-8-0T No. 4248 – 11/11/2023
No. 4248 was built in 1916 at Swindon Works. It is one of the 4200 class of 2-8-0 tank engines designed by George Jackson Churchward. No. 4248 spent most of its working life hauling coal trains in and around South Wales. After being withdrawn from service in 1963 the engine spent many years in Barry Scrapyard. It was rescued from there in 1986.
No. 4248 was purchased for the Museum with the support of a Museums and Galleries PRISM grant. The engine has been conserved at STEAM and is on display as if it is a locomotive under construction in the Boiler Shop area of the museum.
The collection holds a small but varied selection of Great Western rolling stock, which includes Queen Victoria’s Royal Saloon (above) which was built in 1897 and formed part of the Queen Victoria’s Diamond Jubilee train. Another highlight is the beautiful art deco styled Buffet Car No. 9631 built at Swindon in 1934 (below).
Interior of Buffet Car No. 9631 – 11/11/2023STEAM holds a small collection of road vehicles, ranging from horse drawn carts to motorised vans like this Scammell Tractor and Trailer. Road vehicles were an essential part of Great Western operations and were used in and around Swindon Works, good depots and stations – 11/11/2023 Swindon Trip to Weymouth!Display case showing GWR’s nautical connections – 11/11/2023
After our visit to STEAM we met up with Caroline who had been exploring the Designer Outlet. The shopping centre is located on the site of the long shop which was once responsible for erecting steam and diesel locomotives. One such example is GWR 7800 Class 4-6-0 No. 7821 ‘Ditcheat Manor’ which has been on display at the Designer Outlet centre since 2018 when she was moved from the STEAM museum taking the place of sister locomotive No. 7819 ‘Hinton Manor’.
GWR 7800 Class 4-6-0 No. 7821 ‘Ditcheat Manor’ at Swindon Designer Outlet – 11/11/2023 (CS)Nameplate of GWR 7800 Class 4-6-0 No. 7821 ‘Ditcheat Manor’ GWR 7800 Class 4-6-0 No. 7819 ‘Hinton Manor’ at the Swindon Designer Outlet. The locomotive returned to the Severn Valley Railway in August 2018 – 20/02/2014GWR 7800 Class 4-6-0 No. 7819 ‘Hinton Manor’ at the Swindon Designer Outlet – 20/02/2014GWR 7800 Class 4-6-0 No. 7821 ‘Ditcheat Manor’ when she was resident within STEAM museum – 20/02/2014
My next port of call was destined to be Swindon railway station as I was hoping to see and photograph Colas Class 67’s working the Cheltenham to Swindon Transfer Sidings RHTT. However a rare failing on behalf of Google maps, which directed us to the wrong car park, combined with the early running of the class 67’s meant I missed this particular working by a very thin margin. However, this was more than compensated by the DCR Class 60 which worked through the station on a Tytherington to Willesden DC Rail Sidings freight shortly after I arrived on the platform.
Swindon railway station opened in 1842. Until 1895, every train stopped here for at least 10 minutes to change locomotives. Swindon station hosted the first recorded railway refreshment rooms, divided by class – even the King and Queen of the time took refreshments there – 11/11/2023GWR Class 387157 (with 387167) ready to depart Swindon platform 4 working 1B14 1213 London Paddington to Cardiff Central -11/11/2023Freightliner Class 59 No. 59205 ‘L Keith McNair’ thunders through Swindon working 6C48 1147 Appleford Sidings Freightliner Heavy Haul to Whatley Quarry Freightliner Heavy Haul – 11/11/2023DCR Class 60 No. 60046 working east on the approach to Swindon at the head of 6Z52 10:20 Tytherington to Willesden DC Rail Sidings – 11/11/2023Colas Class 66 No.’s 66848 & 66850 ‘David Maidment OBE www.railwaychildren.org.uk’ on the approach to Swindon railway station working 3S59 09:00 Hereford to Swindon Transfer Yard Rail Head Treatment Train – 11/11/2023GWR IET No. 800320 working 1A20 1132 Taunton to London Paddington nears Swindon – 11/11/2023
Video from Swindon – 11/11/2023
The following day we were off to the Isle of Wight to celebrate our friends 50th Wedding Anniversary in Ryde. We chose to leave the car on the mainland and take the hovercraft from Southsea over to the island. The Hovertravel crossing takes a speedy ten minutes.
Griffon 1200TD Hovercraft GH-2160 ‘Solent Flyer’ in service with Hovertravel arrives at the Southsea HoverPort – 12/11/2023
As we arrived into Ryde, I noticed a number of the railway orange army on the pier. Trains that run to Ryde Pier Head station are currently out of action following extensive damage from Storm Ciarán. The Island Line between Ryde Pier Head and Ryde St Johns Road has been closed since the bad weather on 2nd November and engineers are working to reopen the line. South Western Railway (SWR) hope to have trains running on the pier section again by 20th November. Meanwhile, a minibus service is running between Ryde St Johns Road and Ryde Pier Head to allow passengers to connect with ferries.
The rail line had a £26m upgrade in 2021 which saw Island Line’s old 1938 tube trains replaced by refurbished London Underground District Line trains, and its tracks and platforms upgraded. You can revisit our 2022 IoW trip here
The line remains open between between Ryde St Johns Road and Shanklin with two trains per hour running. On our way to the Wedding Anniversary party, we took a slight detour to see SWR Class 484 No. 484002 depart Ryde St Johns Road with a lunchtime service to Shanklin.
SWR Class 484 No. 484002 awaits departure from Ryde St Johns with the 2D33 1332 service to Shanklin -12/11/2023Class 484 units No.’s 484003 and 484005 at Ryde depot – 12/11/2023SWR Class 484 No. 484002 ready for the off from Ryde St Johns with the 2D33 1332 service to Shanklin -12/11/2023
Isle of Wight – 12/11/2023
For The Record:
The New Measurement Train visited North Dorset on 16th November with High Speed Train Class 43 power cars No.’s 43013 and 43277 running as 1Q23 0556 Reading to Salisbury.
Network Rail has confirmed the successful completion of the first phase of works in a wider half a million-pound project to improve reliability on the mainline between Yeovil Junction and Axminster. A five day closure, which was announced at the end of last month, saw key upgrades carried out by engineers who worked day and night at four different sites and included works to stabilise the cutting at Crewkerne tunnel in Somerset following a landslip in October 2021. New drainage and specialist six metre long nails were installed into the earth just outside the tunnel entrance to help lessen the impact of heavy rainfall.
The second phase of the project will see a 16 day closure from Saturday 25th November to Sunday 10th December between Salisbury and Yeovil Junction, when approximately 0.3 miles of track on platform one at Gillingham in Dorset will be replaced and works to stabilise the ground by Gillingham tunnel will be carried out. A further 0.8 plus miles of track will be replaced between Tisbury, in Wiltshire’s Nadder Valley and Sherborne in Dorset and vegetation between Tisbury and Gillingham will be cleared. Maintenance work at the Wyley and Castleton level crossing is also planned. Rail replacement services will run during the two-week line closure.
A British Railways half-flanged green and white enamel steel Yeovil Pen Mill station totem is up for online auction on Thursday November 30th with Leonard Auction
We rather like this nameplate too!
Class 153 DMU Network Rail Video Inspection Unit No. 153385 ran to Bournemouth on Friday 17th November 2023 as 2Q34 0942 Eastleigh East Yard to Eastleigh East Yard. I was picking Yoshi up from the groomer, so missed it!
Class 153 DMU Network Rail Video Inspection Unit No. 153385 at Eastleigh in 2022 – 06/03/2022Yoshi back from the groomer. Better than a Class 153! – 17/11/2023
ASLEF, the train drivers’ union have set dates for further strikes. In a change to previous industrial action, the strikes will be across a whole week split on different days affecting different Train Operating Companies (TOC’s). Union members will walk out at East Midland Railway and LNER on Saturday 2 December; at Avanti West Coast, Chiltern, Great Northern Thameslink, andWest Midlands Trains on Sunday 3 December; at C2C and Greater Anglia on Tuesday 5 December; at Southeastern, Southern/Gatwick Express, South Western Railway main line, South Western Railway depot drivers, and Island Line on Wednesday 6 December; at CrossCountry and Great Western Railway on Thursday 7 December; and at Northern andTransPennine Trains on Friday 8 December.
You’ve made it to the end of this blog entry, there are no prizes, but well done and thank you for reading. We’ll be back soon. Be seeing you!
Postscript:
Class 52 Western Diesel Hydraulic No. D1028 ‘Western Hussar’ in the scrap line at Swindon Works. Built at Swindon in 1964, the locomotive was withdrawn on October 5th 1976. She was cut up a month after this photograph was taken – 13/05/1979D1041 ‘Western Prince’ at Swindon. She was withdrawn from service in February 1977 but was rescued from being cut up by the East Lancashire Diesel Group and is one of the original diesel locos based at Bury – 13/05/1979
Queen Mary 2 alongside Southampton Mayflower Cruise Terminal – 20/10/2023
October 6th 2023 to October 25th 2023
We had a fabulous couple of weeks away cruising on Cunard’s flagship Queen Mary 2 arriving back in Southampton on 20th October where I was quietly pleased to be shown two class 66 locomotives waiting to have their photo taken alongside the Mayflower Cruise Terminal situated at Western Docks via Dock Gate 10 where our ship had berthed.
Class 66’s at Southampton Western Docks – GBRf No. 66729 ‘Derby County’ and DB No. 66143 – 20/10/2023GBRf Class 66 No. 66729 .Derby County’ having worked into Southampton Docks with 4O59 2343 Ditton (O’Connor) GBRf to Southampton Western Docks GB Railfreight – 20/10/2023DB Class 66 No. 66143 at Southampton Western Docks having arrived working 4O63 Kingsbury Birch Coppice Exchange Sidings to Southampton Western Docks Shed 107 – 20/10/2023
We had a lot to catch up on (not least two weeks of laundry!) and I was interested to see how many out off the ordinary railway workings to Dorset and other events I had missed. First up was the launch of Adams T3 No. 563 into service at the Swanage Railway following weeks of test runs and remedial work.
Railway heritage at its very best! An immaculate 1893 built LSWR T3 No.563 in all its glory crosses the viaduct at Corfe – 21/10/2023
Built in 1893 by the London and South Western Railway (LSWR) William Adams T3 4-4-0 No. 563 hauled her first passenger trains in 75 years on 7th October 2023 during a special day celebrating supporters who donated to the £650,000, six year restoration of the Victorian steam locomotive. Designed to haul express trains between London Waterloo and the south coast of England, No. 563 was destined for scrap in 1939 but the outbreak of World War Two saw her being saved and pressed into wartime service. She once again escaped the cutters torch when she helped mark the centenary of London Waterloo railway station in 1948. No. 563 was donated to Swanage Railway Trust by the National Railway Museum (NRM) in 2017.
Guests at the launch ceremony included Swanage Railway Trust patron Sir Philip Williams whose great-grandfather was on the board of the LSWR, the Lord-Lieutenant of Dorset; Angus Campbell, and Anthony Coulls, senior curator of rail transport and technology at the NRM. The relaunch of the locomotive coincided with the centenary of the Southern Railway (SR) and the 185th anniversary of the formation of the LSWR.
Adams 4-4-0 T3 No.563 departs Swanage with a passenger train bound for Norden – 21/10/2023
The T3 ran public services on the 8th October as well as half-term week 21st – 29th October 2023. We went to see the locomotive in service on Saturday 21st.
T3 No. 563 makes a fine scene passing Harman’s Cross – 21/10/2023Also sharing duties with the T3 was SR U Class 2-6-0 No. 31806, seen here departing Swanage with a member of the footplate crew collecting the token from the signalman – 21/10/2023
Video from the Swanage Railway of T3 No. 563 in action – 21/10/2023
For The Record:
Over the last few weeks, a number of interesting workings have taken place in Dorset. Which is typical as I managed to miss most of them!
GBRf liveried Class 50’s returned to Bournemouth employed on South Western Railway (SWR) Class 458 drags on 11th & 12th October 2023 running as 5X72 1044 Wembley Terminal Complex Wheel Lathe to Bournemouth Traction & Rolling Stock Maintenance Depot / 5Q73 1610 Bournemouth Traction & Rolling Stock Maintenance Depot to Widnes Transport Tech. Locomotives involved were No.’s 50007 ‘Hercules’ and 50049 ‘Defiance’ delivering No. 458425 to Bournemouth and taking No. 458416 to Widnes for conversion. The Class 458 units now based at Bournemouth depot have been out on test runs over the last few weeks.
Engineering work west of Yeovil meant buses replaced trains between Yeovil Pen Mill and Weymouth from Monday 16th to Friday 20th October. Network Rail (NR) engineers renewed just under half a mile of old 1950’s era track between Maiden Newton and Chetnole stations. The track update is said to “help prevent speed restrictions and means smoother passenger journeys”. Work also saw repairs being carried out to brickwork at Evershot tunnel and is part of a long-running programme to improve performance on the Heart of Wessex Line. Network Rail and train operators think it is more efficient to close the route for a whole week rather than to shut it for several weekends.
Sign explaining rail replacement bus operations at Dorchester West (image courtesy of Scott Lewis)
Associated engineers trains were as follows; 15th October 2023: 6C04 2349 Westbury Down T.C. to Yeovil Pen Mill – Class 70 No. 70814 17th October 2023: 6C04 02:00 Yeovil Pen Mill to Westbury Down Yard – No. 70814 / 6G22 0202 Westbury Down T.C. to Yeovil Pen Mill – Class 66 No.’s 66709 and 66774 / 6Y88 0921 Westbury Down T.C. to Yeovil Pen Mill – No.’s 66544 and 66556 18th October 2023: 6G22 0837 Yeovil Pen Mill to Westbury Down T.C. – No.’s 66774 and 66709 / 6Y88 11:40 Yeovil Pen Mill to Westbury Down Yard – No.’s 66544 and 66556 / 6Y90 2156 Westbury Down T.C. to Yeovil Pen Mill – No. 66415. 19th October 2023: 6Y90 2334 Yeovil Pen Mill to Westbury Down T.C. – No. 66415
16th & 17th October 2023: saw a rare visit of inspection saloon ‘Caroline’ to the area working as 5Z01 1102 Derby R.T.C.(Network Rail) to Bournemouth Up Siding / 5Z02 0655 Bournemouth Up Siding to Bournemouth / 2Z02 0735 Bournemouth to Southampton Central via Weymouth all involving Class 37 No. 37418 ‘An Comunn Gaidhealach’ along with No. 975025 ‘Caroline’
Class 37 No. 37418 ‘An Comunn Gaidhealach’ with 975025 ‘Caroline’ working as 2Z02 0735 Bournemouth to Southampton Central via Weymouth – 17/10/2023 (video courtesy of G E Barrett)
19th October 2023 1Q23 0556 Reading to Salisbury New Measurement Train in the charge of Class 43 HST power cars No.’s 43251 and 43274 failed when climbing the bank between Exeter St Davids and Exeter Central. The train returned to Exeter St Davids, departing from there at around 1210 and routed towards Taunton, picking up the timetabled path at Westbury some 114 minutes late.
Two engineers trains also visited the Bournemouth area when the 19th and 20th October 2023 saw 6N70 2254 Eastleigh East Yard to Christchurch /6N70 0502 Bournemouth to Eastleigh East Yard top and tailed by Class 66 No.’s 66007 and 66088 whilst on 21st October 2023 6G17 0032 Eastleigh East Yard to New Milton via Bournemouth operated by No.’s 66755 and 66711
23rd October 2023 and it was the return of Network Rail’s Plain Line Pattern Recognition Train (PLPR) hauled, as usual by GBRf Class 73 electro-diesel locomotives which this month were No. 73965 ‘Des O’Brien’ and No. 73964 ‘Jeanette’. PLPR trains use a variety of tools to measure and detect defects in the track which may have the potential to cause problems. Equipment include a 4 foot camera used to check on track condition and thermal imaging to check rail temperatures.
1Q51 1115 Derby R.T.C.(Network Rail) to Eastleigh East Yard at Hamworthy with 73965 ‘Des O’Brien’ and 73964 ‘Jeanette’ – 23/10/2023
A couple of days later on 25th October 2023 and the Ultrasonic Test Train (UTU) was out and about on our patch as 3Q02 2140 Eastleigh East Yard to Eastleigh East Yard. The UTU is usually comprised of a locomotive at one end and a Driving Brake Standard Open (DBSO) at the other. The DBSO can lead the train and control the locomotive at the other end, which was the case on the outward run of 3Q02 to Weymouth this time around. UTU trains have ground penetrating radar systems to detect voids and deformations up to two metres into the ballast and earth below, and use profile scanners to help identify any issues similar to the PLPR test train.
Colas Class 37 No. 37612 in debranded DRS blue livery at the rear of the Ultrasonic Test Train at Poole – 25/10/2023
Class 37 No. 37612 and DBSO No. 9703 working 3Q02 2140 Eastleigh East Yard to Eastleigh East Yard at Poole – 25/10/2023
In the next few weeks, there is more local rail disruption to come affecting trains in North Dorset on the Waterloo – Exeter route as Network Rail will be closing the line between Salisbury and Axminster for 21 days in November and December 2023.
Firstly, the line between between Yeovil Junction and Axminster will be closed for five days between Monday November 6th to Friday November 10th. A second closure takes place between Salisbury and Yeovil Junction from Saturday November 25th to Sunday December 10th. Engineers will be working around the clock to complete key upgrades at four different worksites and upgrades are part of a wider half a million-pound investment to improve reliability and performance along the line. Work will also take place at Crewkerne Tunnel where engineers will attempt to stabilise the cutting following a landslip in October 2021. There will be an installation of new drainage to help to reduce the impact of heavy rainfall. Additional work will take place with the replacement of the barriers at the Broom and Axe level crossing, and the Weycroft River Bridge will have protective, anti-corrosion paint work applied. Areas of waterlogged track stones will be removed.
The Salisbury-Exeter Rail Users Group (SERUG) accepts the maintenance work to track and earthworks is necessary as it says only 77% of services run on time.
Holton Heath railway station – 07/09/2022
In other news, the Poole Harbour Trails community group have successfully registered a disused railway line as a right of way after spending the last 13 years trying to formalise the footpath at Sandford, Poole. The currently overgrown route follows the railway that serviced the Royal Naval Cordite Factory (RNCF) at Holton Heath that closed in the 1950’s and had been used as a path by locals for many years until it became obstructed in 2010. The Friends of the Cordite Way Clearance group received permission earlier this year to start clearance but had to wait for the nesting season to end, beginning work in September on the first section to the viewpoint overlooking Poole Harbour and Arne peninsular. It is hoped to open this first section in the summer of 2024.
Recent research by the walking charity Ramblers found that more than 49,000 miles of paths in England and Wales did not feature on official maps and were at risk of being permanently lost with the government setting a deadline in England of 2031 to apply to get these paths re-registered, however Ramblers believe this deadline should be withdrawn.
Holton Heath railway station – 07/09/2022
Holton Heath railway station is located near the western shore of Poole Harbour and was opened on 3rd April 1916 for use by workers at the Naval Cordite Works which had been established during the First World War. The station was made available for public use from 14th July 1924. Holton Heath has been unstaffed since 1964, with the signal box being removed on 3rd November 1969.
On 20th April 1989 a fatal accident occurred just beyond the siding on the London side of the station, when a light locomotive, which had just completed shunting duties at Winfrith nuclear power station, collided with the rear of a freight train. The driver of the light locomotive, Clive Brooker, died in the accident. Holton Heath railway station – 07/09/2022
Cordite was an explosive component used as a propellant for shells. The factory was built in 1915-16. It was the first purpose-built site for cordite production in the United Kingdom. One of the main ingredients for cordite was acetone. The factory provided its own supply through an acetone plant, which employed novel fermentation technology using maize as a starch source. The RNCF was effectively self-sufficient and had its own internal rail system with about five miles of standard gauge track and 14 miles of narrow gauge, together with its own rolling stock. During the First World War, cordite was dispatched to a jetty in Poole Harbour by rail where it was loaded onto sailing barges for transport to Priddy’s Hard in Gosport. The factory continued to manufacture cordite until 1946. Production at RNCF finally ended in 1957 but many of the buildings still survive.
SWR Class 444 No. 444002 passes No. 444017 at Holton Heath railway station – 07/09/2022
Grand Central Terminal
Sunrise over Manhatten from the deck of Queen Mary 2 – 13/10/2023
We were able to spend a few hours in New York on Friday 13th October 2023. Having never visited the Big Apple previously, I had a short list of things I was hoping to see and Caroline, who has spent time in the city before, was kind enough to indulge me.
QM2 Brooklyn Cruise Terminal. She is too large to dock on the West Side Piers which means passengers require transit to Manhattan – 13/10/2023The NY Water Ferry approaches Red Hook Atlantic Basin, Brooklyn – 13/10/2023
We disembarked the ship at 0700 and were waved through immigration arriving in good time to catch the first water ferry from Red Hook Atlantic Basin, Brooklyn which was adjacent to QM2’s berth over to Manhattan Island.
A NY water Ferry passes QM2, Red Hook, Brooklyn – 13/10/2023
We needed to change ferries at Wall Street to take us up the East river to East 34th Street and following a 42 minute walk we were able to have “Breakfast outside Tiffany’s” before continuing our journey on foot through Times Square and past the New York Library (which was yet to open, but was on my list for a visit to the Polonsky Exhibition of The New York Public Library’s Treasures) to Grand Central Terminal, located at 42nd Street and Park Avenue in Midtown Manhattan.
The Chrysler Building, at 1,046 ft is the tallest brick building in the world with a steel framework, overlooks Grand Central Terminal – 13/10/2023
Grand Central Terminal was designed in the Beaux-Arts style by Reed and Stem – an American architectural and engineering firm founded in Minnesota in 1891 as a partnership between Charles A. Reed (1858–1911) and Allen H. Stem (1856–1931) – who handled the overall design of the terminal, and Warren and Wetmore – a New York architecture partnership between Whitney Warren (1864–1943) and Charles Delevan Wetmore (1866–1941) – which mainly made cosmetic alterations to the exterior and interior.
“Glory of Commerce”, a sculptural group by Jules-Félix Coutan – 13/10/2023
The Beaux-Arts architecture evolved from the French classicism of the Style Louis XIV, and then French neoclassicism beginning with Style Louis XV and Style Louis XV and was the academic architectural style taught at the École des Beaux-Arts in Paris, particularly from the 1830’s to the end of the 19th century. It drew upon the principles of French neoclassicism, but also incorporated Renaissance and Baroque elements, and used modern materials, such as iron and glass, and later, steel. It was an important style in Europe and the Americas through the end of the 19th century, and into the 20th. Various elements inside the terminal were designed by French architects and artists Jules-Félix Coutan (1848–1939), Sylvain Salières (1865–1920), and Paul César Helleu (1859–1927). Grand Central has monumental spaces as well as meticulously crafted detail, especially on its facade, which is based on an overall exterior design provided by Whitney Warren.
I made it to the trains! Grand Central Terminal – 13/10/2023 (CLS)
The Terminal, built on the site of a former railroad depot and phased in over the course of nearly a decade being completed in 1913, covers 48 acres and has over 40 platforms, more than any other railway station in the world. The platforms are all below ground, serving 30 tracks on the upper level and 26 on the lower. In total, there are 67 tracks, including a rail yard and sidings; of these, 43 tracks are in use for passenger services, while the remaining two dozen or so are used to store trains.
Ramp to the Main Concourse, Grand Central Terminal – 13/10/2023
Grand Central Terminal was built and named by the New York Central Railroad which also served the New York, New Haven and Hartford Railroad. The terminal was built on the site of two previous stations, the first of which originated in 1871. Grand Central Terminal served intercity trains until 1991, when Amtrak began routing its trains through nearby New York Penn Station. Grand Central is now the southern terminus of the Metro-North Railroad’s Harlem, Hudson and New Haven Lines, serving the northern parts of the New York metropolitan area. It also contains a connection to the Long Island Rail Road through the Grand Central Madison station as well as connecting to the New York City Subway at Grand Central–42nd Street station. The terminal is the third-busiest railway station in North America.
The Main Concourse at Grand Central – 13/10/2023
The Main Concourse is located on the upper platform level of Grand Central, in the centre of the station building. The 35,000 square foot area leads directly to most of the terminal’s upper-level tracks. In their design for the station’s interior, Reed & Stem created a circulation system that allowed passengers alighting from trains to enter the Main Concourse, then leave through various passages that branch from it. The Main Concourse, often featured in films and television, is a busy space filled with people hurrying to their destination or onlookers taking in the grandeur of their location.
The four-sided brass clock at Grand Central – 13/10/2023 (CLS)
At the centre of the concourse is an information booth topped with a four sided brass clock, one of Grand Central’s most recognisable icons. The terminal’s main departure boards are located at the south end of the concourse.
The Main Concourse, Grand Central Terminal with the train information boards on the left hand side of the image – 13/10/2023
Grand Central Terminal contains a variety of stores and food vendors, including restaurants and bars, a food hall, and a grocery marketplace. The building is also noted for its library, event hall, tennis club, control centre and offices for the railroad, and sub-basement power station.
Ramp to the Dining Concourse, Grand Central – 13/10/2023The Oyster Bar – 13/10/2023Dining Concourse, Grand Central Terminal – 13/10/2023
Ramps include the Vanderbilt Avenue ramp and the Oyster Bar ramps. The Oyster Bar ramps lead down from the Main Concourse to the Oyster Bar and Dining Concourse.
Jacqueline Kennedy Onassis Foyer – 13/10/2023
The main entrance into the terminal, underneath the Park Avenue Viaduct, opens into the Jacqueline Kennedy Onassis Foyer, so named in 2014 in honour of the former First Lady of the United States, who in the 1970’s helped prevent the demolition of the Main Concourse and the plan to build Grand Central Tower.
Vanderbilt Hall , Grand Central Terminus – 13/10/2023
Vanderbilt Hall is an event space on the south side of the terminal, between the main entrance and the Main Concourse to its north. The north and south walls are divided into five bays, each with large rectangular windows, screened with heavy bronze grills. The room is lit by Beaux-Arts chandeliers, each with 132 bulbs on four tiers. Vanderbilt Hall was formerly the main waiting room for the terminal, used particularly by intercity travellers.
After exploring this wonderful building we headed back out into the streets and walked back to the NY Library to find the original Winnie The Pooh and friends who had been donated in 1987 having been brought to the United States by A.A Milne’s (1882-1956) US publisher; Elliott Macrae (1901-1968) former President of E.P. Dutton in 1947.
The Statue of Liberty stands on Liberty Island in New York Harbour seen behind QM2 – 13/10/2023The Statue of Liberty – 13/10/2023
From the Archive:
A few images from 2020, that strange time when we all spent months staying indoors only going outside for an hours exercise a day. During the Covid pandemic, cruise ships were forced out of work and laid up at anchor in various harbours and ports around the UK, Weymouth being no exception.
RMS Queen Mary 2 in Weymouth Bay – 07/08/2020
RMS Queen Mary 2 introduced in 2003 was, at that time; the largest, longest, widest, tallest grandest and most expensive ocean liner ever built. She replaced the beloved QE2 on the transatlantic run and as flagship of the Cunard line. Queen Mary 2 has a maximum speed of just over 30 knots and a cruising speed of 26 knots which is faster than a contemporary cruise ship. She had the Royal Mail Ship (RMS) prefix conferred on her by the Royal Mail when she entered service in 2004, as a gesture to Cunard’s history. Onboard facilities include fifteen restaurants and bars, five swimming pools, a casino, a ballroom, a theatre, and the first planetarium at sea. Queen Mary 2 is powered primarily by four diesel engines supplemented by two gas turbines which provide extra power as and when required.
QM2 employs a quadruple podded propeller propulsion system which like giant outboard motors hang under the ship replacing the need for traditional propeller shafts. The forward pair of thrusters is fixed, but the aft pair can swivel through 360°, removing the need for a rudder. Queen Mary 2 carries eight spare blades on her foredeck. The ship is also fitted with three bow thrusters which allow the ship to turn in its own length while in port, to conduct more complex docking manoeuvres. The pods fitted to Queen Mary 2 have been prone to failure despite redesigns. In January 2009, Cunard sued the manufacturers Rolls-Royce in the United States claiming the design of the pods were inherently defective, and that Rolls-Royce knew about the design deficiencies and deliberately conspired to mislead, deceive and defraud in the course of winning the contract. In January 2011, the court awarded Carnival US$24 million.
During the pandemic the cruise ships would make regular sorties along the south coast and returning to port for supplies and crew changes, Queen Mary 2 is seen here as she departs Weymouth on one such outing – 06/05/2020
When Covid-19 started to spread across the globe in 2020, Queen Mary 2 was enjoying a world cruise. In early February, Cunard cancelled the Asian leg of the voyage, with the remainder of the journey being cancelled on 15th March. Passengers were disembarked in Fremantle, Western Australia, with the ship returning to Southampton in April.
QM2 arrives into the bay at Weymouth – 17/12/2020A stern view of Queen Mary 2 seen from one of the tourist boats which ran trips around Weymouth Bay for close up encounters with the anchored cruise ships – 07/08/2020Yoshi on Weymouth esplanade with cruise ships in the background – 06/09/2020Cunard’s Queen Victoria, Weymouth Bay – 07/08/2020Queen Elizabeth, Weymouth – 07/08/2020Yoshi enjoyed walks along the beach as we watched the cruise ships. Three Cunard Queens along with P&O and TUI’s Marella vessels are behind him in this image – 07/08/2020Three Cunard Queen’s lined up together in Weymouth Bay – Queen Victoria, Queen Elizabeth and Queen Mary 2. This was the only time I think I managed to photograph the Cunard fleet without any other interlopers between them – 23/08/2023
A bit of a mixed bag on this occasion, but that’s all we have time for! Thanks for reading and hopefully we’ll be back with another instalment soon. Until then, take care. Be seeing You!
It was lovely to be reunited with our boy as we disembarked QM2 last Friday. He was excited to see us again after being separated for over two weeks. A huge thank you to my brother and family for taking such good care of Yoshi xXx
References used for the Grand Central Terminal section:
Charles River Editors Grand Central Station: The History of New York City’s Famous Railroad Terminal, (CreateSpace Independent Publishing Platform 2015)
Metro-North Railroad (2023) Grand Central Retrieved from https://www.grandcentralterminal.com
Wikipedia (October 24, 2023) Grand Central Terminal Rettrieved from https://en.wikipedia.org/wiki/Grand_Central_Terminal
Yoshi meets Adams T3 4-4-0 No. 563 at Norden as the locomotive, complete with tender, is steamed for the first time in 75 years – 22/09/2023
September 20th 2023 to September 27th 2023
The big local news this week was centred on the Swanage Railway as Victorian era Adams T3 Class 4-4-0 locomotive No. 563 was reunited with her tender after remedial tasks were carried out at Herston Works and steamed while complete for the first time in around 75 years. Yoshi and I headed over to Corfe Castle railway station on Friday 22nd September with the objective of capturing her running light engine to Swanage. Road works in Corfe village delayed our arrival at the station and we were not sure if we had missed the action but after waiting a few minutes or so, the signalman at Corfe box told us he was off to have his lunch and there would be nothing running for the foreseeable. With this nugget of information, Yoshi and I jumped back into the car and headed back to Norden where we found the steaming T3 gleaming in the sunshine.
Beautifully restored Adams T3 4-4-0 No. 563 at Norden – 22/09/2023
We busied ourselves taking a few photographs and saying hello to Nathan Au from the 563 Locomotive Group who very kindly updated us with the information that the T3 was not likely to move from Norden for quite possibly two hours as various bits and bobs needed fitting to the locomotive and adjustments made. With one eye on the time, Yoshi and I headed home as we had other early afternoon commitments, during which we kept one eye on the Swanage railway webcams. Or rather I did, as Yoshi took time to snooze at my feet.
Viewing the webcams paid off as I saw the T3’s arrival in Swanage during a brief spell of rain at around 1500. Not knowing if the locomotive was set to run any additional test runs that day we went straight to Swanage to find the T3 simmering on the turntable. After another period of rain, expectations grew as coal was shovelled into the T3’s firebox and eventually the locomotive eased into movement, running into the station mouth and back out up to one of the sidings beyond the engine shed. Although I had missed what turned out to be the solitary the test run that day, I was happy to have at least seen No. 563 move under its own power!
Adams T3 4-4-0 No. 563 on shed at Swanage – 22/09/2023Adams T3 4-4-0 No. 563 beneath the coaling stage at Swanage – 22/09/2023Adams T3 4-4-0 No. 563 meets “Greyhound” T9 No. 30120 owned by the National Collection is based on the Swanage Railway after an agreement was reached between the National Railway Museum and the Swanage Railway Trust which will see the 1899 built London & South WesternRailwaylocomotive stored at the Purbeck heritage line following expiry of its boiler certificate in August 2020, which meant the T9 had to be taken out of use. The new agreement includes provision for a limited disassembly of the locomotive – including a boiler lift – so that the Swanage Railway Trust can assess the potential for the locomotive to be returned to steam. Designed by Dugald Drummond (1st January 1840 – 8th November 1912), No. 30120 was built at the Nine Elms Locomotive Works in London. During the Second World War, the T9 was attacked by a German Luftwaffe fighter at Wool station with the locomotive crew having to hide under No. 30120 for cover. The locomotive was withdrawn in 1961 from Exmouth Junction shed in Devon, and joined the National Collection in late 1963 with No.30120 later being put on display at the National Railway Museum in York. In 2010, the locomotive was overhauled at the Flour Mill engineering works, in the Forest of Dean, for service on the Bodmin and Wenford Railway, in Cornwall before moving to the Swanage Railway in 2017. The T9 had previously hauled trains on the Swanage Railway in 1991 when passenger trains only operated on the three miles from Swanage to Harman’s Cross and was the first steam locomotive to run to Corfe Castle since June 1967 after relaid tracks reached Corfe Castle en route to Norden – 22/09/2023Two Victorian era locomotives at Swanage; Adams T3 4-4-0 No. 563 and Drummond T9 4-4-0 No. 30120 – 22/09/2023Swanage shed and turntable with T9 No. 563 and T9 No. 30120 – 22/09/2023Adams T3 4-4-0 No. 563 moving under her own steam chuffs out of Swanage – 22/09/2023Passing Class 33/0 No. 33012 / D6515 ‘Lt Jenny Lewis RN’, Adams T3 4-4-0 No. 563 heads to a siding at Swanage following a successful test run under her own steam for the first time in 75 years – 22/09/2023Class 33/0 No. 33012 / D6515 ‘Lt Jenny Lewis RN’ at Swanage – 22/09/2023A cavalcade of locomotives at Swanage as Class 08 No.08436 ‘Beighton’ shunts steam locomotives around the station area at Swanage – 22/09/2023
Adams T3 4-4-0 No. 563 at Swanage in steam for the first time in 75 years – 22/09/2023
The weekend of 23/24th September saw another set of engineering work taking place in the Parkstone area on the down line. The work site was a continuation from where last weeks ended and this time continued through to Parkstone railway station itself. The need for the work to be carried out had apparently been identified by one of the monthly plain line pattern recognition (PLPR) trains. Further tamping of the new line is required in the coming weeks. There is no requirement for the up line to be replaced at present.
Colas Class 70 No. 70803 at Parkstone having worked in with 6C03 2356 Eastleigh East Yard to Branksome – 23/09/2023Colas Class 70 N0. 70809 on Parkstone bank which arrived as 6C04 0242 Eastleigh East Yard to Bournemouth – 23/09/2023GBRf Class 66 No. 66760 ‘David Gordon Harris’ arrives at the Parkstone worksite with 6G10 0524 Eastleigh East Yard to Bournemouth – 23/09/2023GBRf Class 66 No. 66721 ‘Harry Beck’ working 6G11 0635 Eastleigh East Yard to Bournemouth moves slowly up to join the Permanent Way works at Parkstone – 23/09/2023DB Cargo Class 66 No. 66131 approaches Christchurch appropriately working 6N31 1113½ Eastleigh East Yard to Bournemouth – 23/09/2023EWS liveried DB Cargo Class 66 No. 66181 at Milton Road bridge forming 6N32 1313½ Eastleigh East Yard to Bournemouth – 23/09/2023GBRf Class 66 No. 66721 named in tribute to ‘Harry Beck’ designer of the London Underground map which has been replicated throughout the World at rest on Parkstone bank – 23/09/2023GBRf Class 66 No. 66721 ‘Harry Beck’ with a train of fresh ballast at Parkstone – 23/09/2023Work taking place to relay the down tracks through Parkstone railway station – 23/09/2023As part of an charity auction, GBRf gave the opportunity to name a locomotive to one lucky winner who donated what has quoted to have been “an extraordinary amount of money” to good causes and chose to name Class 66 No. 66760 after his father, a career train driver celebrating his 60th birthday; ‘David Gordon Harris’. The loco is seen here running through Poole railway station heading for Holes Bay – 23/09/2023In Genesee & Wyoming livery, Freightliner Class 66 No. 66509 ‘Josiah’s Wish’ is about to set off from Holes Bay, Poole to form 6N32 1855 Bournemouth to Eastleigh East Yard – 24/09/2023
Yoshi and I managed to photograph all but one locomotive involved in the engineering possession over the weekend – the loco evading our camera lens being Freightliner Class 66 No. 66420 which worked in with fellow class member No. 66509 ‘Josiah’s Wish’ on 23rd September’s 6Y83 2040 Eastleigh East Yard to Bournemouth – although we did see its exhaust as we drove above the track via Station road bridge on our way to Castlepoint shopping centre on Sunday morning! No. 66420 returned as 6Y83 1755 Bournemouth to Eastleigh East Yard, but again I was unable to see this move.
Engineering work at Parkstone – 23/09/2023
Monday evening was the return of the Class 73 top and tailed PLPR train which travelled from Derby Railway Technical Centre down to Weymouth and back to Eastleigh East Yard. Class 73 Electro Diesels No. 73964 ‘Jeanette’ and 73962 ‘Dick Mabbutt’ were picked from the rergular roster of locomotives. We decided on seeing them this time on the outward run through Parkstone so we could admire the new track which was as mentioned above the result of a previous run of this particular test train.
1Q51 1115 Derby R.T.C.(Network Rail) to Eastleigh East Yard – 25/09/2023
Tuesday was highly anticipated with the scheduled run of a CrossCountry High Speed Train to Swanage designed as a farewell celebration to the XC HST fleet after more than 40 years of operation on across the UK. Proceeds from the trip were in aid of The Brain Tumour Charity in remembrance of CrossCountry employee Jo Taylor, who passed away in 2021. Jo was a popular member of the CrossCountry family and was a familiar face to many, having worked at both Leeds and Bournemouth over her 14 years with the company. This excursion train actually comprised of two tours with the “Pines Express” section running from Leeds to Swanage and return, and the “Bournemouth Belle” from Swanage to Bournemouth and return making use of the HST set in the afternoon. The train was a joint venture with CrossCountry, Modern Railways magazine and The Branch Line Society in association with the Swanage Railway alongside support from Porterbrook and Angel trains.
Retro Inter-City 125 liveried Class 43 No. 43007 departs Bournemouth with “The Pines Express” 1Z43 0635 Leeds to Swanage – 26/09/2023Inter-City Swallow liveried Class 43 No. 43008 departs Bournemouth at the rear of “The Pines Express” 1Z43 0635 Leeds to Swanage – 26/09/2023XC Class 43 No. 43008 crosses Corfe Viaduct working “The Bournemouth Belle” 1Z25 1310 Swanage to Bournemouth – 26/09/2023Class 43 No. 43008 awaits departure from Wareham with 1Z25 1310 Swanage to Bournemouth – 26/09/2023Class 43 No. 43008 carried the “Pines Express” headboard while working 1Z25 1310 Swanage to Bournemouth – 26/09/2023Class 43 No. 43007 passes Wareham signal box at the rear of 1Z25 1310 Swanage to Bournemouth – 26/09/2023Class 43 HST power cars No.’s 43007 and 43008 top and tail 1Z26 1452 Bournemouth to Swanage across Holes Bay, Poole – 26/09/2023Class 43 No. 43008 leads the return “Bournemouth Belle” 1Z44 1618 Swanage to Leeds nearing Harman’s Cross – 26/09/2023CrossCountry High Speed Train Farewell headboard – 26/09/2023Class 43 No. 43007 at the rear of 1Z44 1618 Swanage to Leeds passing through Harman’s Cross – 26/09/2023Captured by the gallery, Class 43 No. 43008 1Z44 1618 Swanage to Leeds at Holton Heath – 26/09/2023Class 43 No. 43007 at the rear of 1Z44 1618 Swanage to Leeds having cleared Holton Heath – 26/09/2023Retro liveries applied to (TOP) No. 43007 and (BOTTOM) No. 43008 – 26/09/2023
CrossCountry High Speed Train Farewell – 26/09/2023
It was great to see so many friends and fellow enthusiasts out on the day capturing images, video and memories of what is most likely the final scheduled public CrossCountry High Speed Train run. Our North Dorset Correspondent, Scott, travelled on the “Bournemouth Belle” mini-special and was able to kindly share images of the following goodies he picked up onboard:
Coaster of the CrossCountry Farewell HST publicity posterWindow stickers available for purchase on the trainCrossCountry HST Farewell BookletThe special Bournemouth Belle Swanage to Bournemouth souvenir ticketA set of CrossCountry themed HST pin badges were available for passengers to buy
Due to planned industrial action, a CrossCountry staff outing to Blackpool North from Plymouth that had been arranged for the 29th September has been cancelled.
Tuesday evening after all the HST excitement, a pair of preserved Class 50 locomotives were employed on a GBRf Class 458 EMU drag from Widnes Transport Tech to Bournemouth depot. However, due to slack oversight and ‘schoolboy’ error, I failed to notice the train worked early after it failed to observe a timetabled 40 minute layover at Brockenhurst. Despite a valiant effort from Jamie, we didn’t make it to Branksome in time to see the ensemble manoeuvre into the depot, arriving 53 minutes early as 5X72 1435 Wembley Receptions 1-7 to Bournemouth T&R.S.M.D.
However, what goes into Bournemouth Depot has to also come out again, and the following day; Wednesday 27th September 2023, saw a return working to Widnes taking an un-refurbished Class 458 unit for conversion. I really thought the train would depart early and kept a weather eye on the Open Time Trains map for movement! In the event the working; 5Q73 1712 Bournemouth T&R.S.M.D to Widnes Transport Tech, left one minute early and by that time we were safely ensconced on the platform at Branksome, just outside the junction to the depot. Unsurprisingly the attraction of such unusual motive power attracted a number of fellow enthusiasts and the station was very busy.
English Electric Class 50 No. 50007 ‘Hercules’ runs through Branksome with 5Q73 1712 Bournemouth T&R.S.M.D to Widnes Transport Tech – 27/09/2023Class 50 No. 50049 ‘Defiance’ in GBRf livery awaits the off at Branksome working 5Q73 1712 Bournemouth T&R.S.M.D to Widnes Transport Tech – 27/09/2023Moving slowly away from Branksome, Class 50 No. 50049 ‘Defiance’ leads with 5Q73 1712 Bournemouth T&R.S.M.D to Widnes Transport Tech – 27/09/2023
5Q73 1712 Bournemouth T&R.S.M.D to Widnes Transport Tech – 27/09/2023
For The Record
North Dorset saw the New Measurement Train pass through on Thursday 21st with Colas Class 43 HST Power Cars No’s 43277 and 43274 in charge.
Preparatory work for the installation of new walking and cycling bridges across the railway line on Glenferness Avenue in Bournemouth started in May this year following public consultation on proposals undertaken 24th February to 31st March 2021. Funded through South East Dorset’s Transforming Cities Fund (TCF), the work forms part of a planned sustainable travel route linking Bournemouth town centre and Ferndown and will see the installation of a four metre wide bridge for pedestrians and cyclists over the railway line on the west side of the road bridge. The existing footbridge on the eastern side of the road bridge will be demolished on site and replaced with a new four metre wide pedestrian and cycle bridge, the existing road bridge remaining unaltered.
The installation of the new bridges and removal of the existing pedestrian bridge is programmed to commence during a 26 hour window from Sunday 1st October to Monday 2nd October 2023. Impressive crane action is promised with the first new bridge being lifted into position on the west side of the road bridge and placed onto the precast concrete foundations. This will be followed by the removal and recycling of the existing footbridge. The installation of the new bridge on the east side of the road bridge will complete the process.
Following the bridge installation work, bridge ramps and stepped cycle lanes will be built on Glenferness Avenue between Elgin Road and Alyth Road. This work is anticipated to complete by December. The new bridges will give people a separate, safe, traffic free space to walk, cycle and wheel across the railway line. They form a crucial part of a sustainable travel route between Bournemouth town centre and Talbot Woods, Winton and Wallisdown and future plans for the route all the way out to Ferndown.
From The Archive
Taking a look at previous visits of High Speed Trains to the Swanage Railway.
First Great Western (FGW) High Speed Train at Wareham with Class 43 No. 43028 leading the 1Z12 Cotswold – Purbeck Express to the Swanage Railway having originated from Worcester Shrub Hill departing at 0732. This photograph was taken by a Network Rail staff member from a position of safety for John Chappell who is standing second from the right – 28/09/2013
Back in September 2013 the first High Speed Train ventured onto the Swanage Railway with the “Cotswold – Purbeck Express” organised by the Cotswold Line Promotion Group. Because of gauging issues, the train terminated at Corfe Castle where a connecting service to Swanage was provided.
FGW Class 43 power car No. 43078 at Corfe Castle (John Chappell) – 28/09/2013FGW Class 43 power car No. 43078 at Corfe Castle (John Chappell) – 28/09/2013Close up of FGW Class 43 power car No. 43078 after departing Corfe Castle (John Chappell) – 28/09/2013FGW Class 43 power car No. 43078 leading away from Corfe Castle and crossing Corfe Viaduct (John Chappell) – 28/09/2013The return Cotswold – Purbeck Express 1Z13 1610 Swanage to Worcester Shrub Hill pauses at Wareham with leading power car FGW Class 43 No. 43078 at the head of the train (John Chappell) – 28/09/2013
The following year, in June 2014 “The Swanage Samaritan” railtour was a special train organised for East Midlands Trains (EMT), South West Trains (SWT) and their guests. The excursion which originated from Sheffield raised funds for the Samaritans charity and saw the first High Speed Train actually reach Swanage, the gauging issues preventing the previous trip from travelling all the way down the branch obviously having been sorted!
East Midlands Trains HST Class 43 power car No. 43089 at journeys end in Swanage having arrived working 1Z43 0613 Sheffield to Swanage (John Chappell) – 14/06/2014HST, Class 33 and Class 08 line up at Swanage (John Chappell) – 14/06/2014Class 43 No. 43064 with “The Swanage Samaritan” headboard at the buffer stops at Swanage Railway station (John Chappell) – 14/06/2014Class 43 No. 43064 carried temporary South West Trains branding for the tour (John Chappell) – 14/06/2014Class 43 power car No. 43089 about to cross Corfe Viaduct with the return “The Swanage Samaritan” 1Z44 1614 Swanage to Sheffield (John Chappell) – 14/06/2014Class 43 No. 43064 brings up the rear of “The Swanage Samaritan” 1Z44 1614 Swanage to Sheffield having departed Corfe Castle (John Chappell) – 14/06/2014EMT Class 43 power car No. 43089 pauses at Wareham on its way back to Sheffield (John Chappell) – 14/06/2014
That’s it for another week. Many thanks to those who kept me company while out watching the T3, HST’s and Class 50’s, I appreciate it. And thank you for comments, suggestions and corrections for Yoshi’s blog. Be seeing you!
The sun sets on the final CrossCountry scheduled HST passenger service with Class 43 No. 43008 leading 1E73 1627 Plymouth to Leeds (No. 43007 was at the rear) on the approach to Foal Mead Viaduct – 18/09/2023
September 13th 2023 to September 19th 2023
Wednesday 13th September 2023 saw what I believe to be the final steam hauled excursion of the year to pass through our neck of the woods. Once again LMS Jubilee 4-6-0 No. 46995 ‘Bahamas’ headed a Railway Touring Company railtour, this time travelling from London Victoria through to the heritage Swanage Railway. We saw the outward bound leg as the train passed Poole Storage Sidings. As yet, there are no facilities to turn a steam locomotive on the Swanage Railway and on the return the tour was diesel hauled as far as Southampton Central by West Coast Railways Class 47 No. 47746 ‘Chris Fudge’. The loco was named after Chris Fudge who passed away following a long battle with a brain tumour in 2010. Chris garnered an interest in trains from an early age and went on to work for the railways, his final role being a timetable planning manager for Arriva trains.
LMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ works “The Swanage Belle” 1Z91 0815 London Victoria to Swanage out of Poole – 13/09/2023LMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ heading 1Z91 0815 London Victoria to Swanage passes South Western Railway Class 444 EMU No. 444001 at Poole Storage Sidings – 13/09/2023
We watched the late afternoon return at Hamworthy (and still home for dinner!)
West Coast Railways Class 47 No. 47746 ‘Chris Fudge’ works the return “Swanage Belle” 1Z92 1555 Swanage to London Victoria on the approach to Hamworthy – 13/09/2023LMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ at the rear of 1Z92 1555 Swanage to London Victoria passes through Hamworthy – 13/09/2023
LMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ on “The Swanage Belle” – 13/09/2023
Wednesday night, I set out for Poole as the second Permanent Way (PW) train of the week was timetabled to pass through the station just after midnight and reverse at Poole Storage Sidings to drop lengths of new rail at Parkstone in readiness for engineering work over the weekends of 16/17th and 23/24th September. The earlier run, reported on in last weeks blog entry, was operated by DB Cargo whereas the Thursday run was in the hands of Colas Rail who sent Class 66 No.’s 66847 ‘Terry Baker’ and 66850 working as 6C17 2240 Eastleigh East Yard to Parkstone (Dorset). Unlike previously, the engineers train did not stop as booked in Poole station and I had to be content with taking photographs of South Western Railway Desiro’s. The associated return working of the PW train ran as 6C17 0507 Bournemouth to Eastleigh East Yard when I was tucked up in bed!
Class 450 No. 450084 at Poole having arrived with the 2B73 2316 Brockenhurst to Poole service – 13/09/2023
Colas Class 66 No.’s 66847 ‘Terry Baker’ and 66850 working 6C17 2240 Eastleigh East Yard to Parkstone (Dorset)- 14/09/2023
On Friday we took the opportunity provided by Heritage Open Days to visit Morgan Carey Architects in Wareham who restored the former Goods Shed for use as their offices. Originally constructed in red brick with a hipped slate roof in circa 1847 for the Southampton and Dorchester Railway, Morgan Carey have completed a stunning and sensitive restoration using as much original materials as possible. We very much enjoyed our visit and thanks to Mark for showing us around.
The former Goods Shed at Wareham – 15/09/2023A length of track marks the course of the rail line into the former Goods Shed at Wareham which is now the entrance to Morgan Carey Architects – 15/09/2023The new roof of the former Goods Shed in Wareham, the original roof having been destroyed by fire prior to the conversion work – 15/09/2023Rear of the former Goods Shed at Wareham showing what would have been access to the platform level – 15/09/2023
As mentioned above, the past weekend saw a number of engineering trains visit the Poole area as work necessitated the closure of the railway line between Bournemouth and Wareham. Buses ran between these two points, connecting passengers with trains running a revised service for onward journeys. Yoshi and I spent most of Saturday shuttling between Christchurch and Hamworthy in our attempts to see and document the work as a section of the down line west of Branksome was relayed. Track lifting started at a point near milepost 111 and extended under St. Osmunds and Sandecotes Road bridges down Parkstone Bank towards the station. The somewhat heavy rain on Sunday morning curtailed our observations and we refrained from going out to see the return workings of the engineers trains. Maybe we’ll do that next Sunday! I hope the following images capture a flavour of the activities being carried out.
GBRf Class 66 No. 66796 ‘The Green Progressor’ arrives at Bournemouth working 6G13 0709 Eastleigh East Yard to Bournemouth – 16/09/2023Colas Rail DR73931 Track Maintenance Tamper in the siding at Bournemouth – 16/09/2023DB Cargo Class 66 No. 66176 at Christchurch at the head of 6N01 0809 Eastleigh East Yard to Bournemouth – 16/09/2023GBRf Class 66 No. 66707 ‘Sir Sam Fay Great Central Railway’ west of Branksome railway station – 16/09/2023Yoshi was pleased to tick off seeing GBRf Class 66 No. 66796 ‘The Green Progressor’ at Branksome – 16/09/2023Colas Class 66 No.66847 ‘Terry Baker’ passes through Poole with a train load of lifted track panels – 16/09/2023DB Cargo Class 66 No. 66200 6N02 1048 Eastleigh East Yard to Bournemouth – 16/09/2023DB Cargo Class 66 No. 66200 in the distance with its train of new ballast at the Parkstone worksite as work continues – 16/09/2023GBRf Class 66 No. 66707 ‘Sir Sam Fay Great Central Railway’ at Parkstone prior to running down through Poole and spending the night near Hamworthy – 16/09/20236C04 1348 Eastleigh East Yard to Bournemouth hauled by Colas Rail 66849 ‘Wylam Dilly’ passing Pokesdown – 16/09/2023With a train of wagons being filled with old ballast, DB Cargo Class 66 No. 66176 at the western extreme of the worksite – 16/09/2023DB Cargo Class 66 No. 66176 on Parkstone Bank – 16/09/2023Colas Class 70 No. 70803 speeds through Christchurch at the head of 6C05 1653 Eastleigh East Yard to Bournemouth – 16/09/2023DB Cargo Class 66 No. 66007 having worked 6N03 2154 Eastleigh East Yard to Bournemouth – 17/09/2023DB Cargo Class 66 No. 66199 at Branksome with a train of fresh ballast – 17/09/2023Another view of DB Cargo Class 66 No. 66199 at Branksome – 17/09/2023DB Cargo Class 66 No. 66007 at the work site – 17/09/2023DB Cargo Class 66 No. 66106 on Parkstone bank – 17/09/2023Colas Class 70 No. 70803 adjacent to Poole Storage Sidings in heavy rain. Plastic tents can be seen covering point work beyond where work was being carried out – 17/09/2023DB Cargo Class 66 No. 66199 and Colas Rail DR73931 Tamper at Parkstone – 17/09/2023DB Cargo Class 66 No. 66007 stands in Poole station – 17/09/2023Colas Rail Class 70 No. 70803 seen from Sterte Road Bridge – 17/09/2023
For the record, the incoming Permanent Way trains began to leave Eastleigh East Yard late on Friday 15th September with the majority arriving in Dorset on the Saturday.
As each train fulfilled its need, collecting old track panels, empty wagons for the collection of old ballast or wagons full of new stone, most then passed through Poole and were stacked across Holes Bay awaiting their return to Eastleigh which commenced on Sunday evening.
Trains were stacked across the Holes Bay causeway while not in use. An early morning view of Colas Class 66 No. 66849 ‘Wylam Dilly’ and DB Cargo No. 66200- 17/09/2023The view across Holes Bay – 17/09/2023GBRf Class 66 No. 66707 ‘Sir Sam Fay Great Central Railway’ seen amidst the trees of Upton Park – 17/09/2023Colas Class 66 No.66847 ‘Terry Baker’ sits above Blandford Road, Hamworthy – 17/09/2023
The workings and the associated motive power were:
6C03 2355 Eastleigh East Yard to Branksome – Colas Rail No. 66847 ‘Terry Baker’
6G12 0315 Eastleigh East Yard to Bournemouth – GB Railfreight No. 66707 ‘Sir Sam Fay Great Central Railway’
6G13 0709 Eastleigh East Yard to Bournemouth GB Railfreight No. 66796 ‘The Green Progressor’
6N01 0809 Eastleigh East Yard to Bournemouth DB Cargo No. 66176
6N02 1048 Eastleigh East Yard to Bournemouth DB Cargo No. 66200
6C04 1348 Eastleigh East Yard to Bournemouth Colas Rail No. 66849 ‘Wylam Dilly’
6C05 1653 Eastleigh East Yard to Bournemouth Colas Rail No. 70803
6N03 2154 Eastleigh East Yard to Bournemouth DB Cargo No. 66007
6N04 2352 Eastleigh East Yard to Bournemouth DB Cargo No.’s 66199 and 66106
Video of Dorset Permanent Way trains over the weekend of 16/17th September 2023
As an aside, North Dorset also saw engineering work take place on Sunday 17 September 2023 when the West of England main line was closed between Templecombe and Gillingham. As far as I’m aware there were no PW trains allocated to this work.
Monday 18th September 2023 saw the final chapter for CrossCountry HST’s in use for scheduled passenger trains across the UK network. I was in two minds if to head out and see the last working heading from Plymouth to Leeds as the weather wasn’t particularly good on the day. However, with a few hours respite from the rain forecast and the XC trains on divert via Castle Cary and Westbury because of engineering work in the Worle area, I set off towards Langport as I was hopeful of photographing the train at Foal Mead Viaduct. Located just outside the small town of Langport, the structure consists of two half through girder spans, a truss span and two masonry arch spans. It’s a lovely spot where the main line between Cogload Junction and Castle Cary crosses the River Parrett and I was inspired to seek the location out after seeing recent photos taken by Robin Procter.
To find out about the recent renovation work on the viaduct carried out by Taziker and the challenges this presented, look here.
InterCity Swallow liveried CrossCountry HST Class 43 power car No. 43008 leading 1E73 1627 Plymouth to Leeds crossing Foal Mead Viaduct – 18/09/2023The final full length timetabled HST CrossCountry working crosses the River Parrett. The iron lattice girder railway bridge built in 1853, was recently totally refurbished as part of a major works to re-stabilise the earth embankment close to its approaches – 18/09/2023CrossCountry HST Class 43 power car No. 43007 in retro British Rail livery at the rear of 1E73 1627 Plymouth to Leeds crossing Foal Mead Viaduct, also know as Langport Viaduct or Pool Mead Viaduct, constructed 1900-1906 in RBE brick with 10 spans – 18/09/2023
Two tours are planned to celebrate the XC farewell to the HST, the first being a public tour between Leeds, Swanage and Bournemouth on the 26th September, followed by a staff jolly between Plymouth and Blackpool North on the 29th.
A Multi-Purpose Vehicle (MPV) running a rail head treatment working ran from Totton Yard to Swanage on Monday 18th September 2023. I wasn’t able to go and see the Network rail machine on heritage rails, but with the magic of the Swanage Railway webcam, I was able to watch some of its activities.
Network Rail MPV DB98920 + DB98970 arrives at Corfe Castle as 6Z21 0935 Totton Yard to Swanage – 18/09/2023Rail Head Treatment Train Network Rail MPV DB98920 + DB98970 6Z21 0935 Totton Yard to Swanage passes Class 33 No. 33111 at Swanage – 18/09/2023
Hamworthy Branch Update: Along with the already reported Network Rail work for a bridge inspection which sees the closure of Lake Road from its junctions with Normandy Way/Lake Drive to its junction with Coles Avenue on 21st November 2023 at 2100 until 0500 the following morning, there is a further planned closure in January 2024. This time the road will be closed for what are described as “Works for Rail Purposes” from 2200 on the 8th January 2024 until 0600 on the 12th January 2024.
We asked Network Rail for an update on the Hamworthy Branch and they responded: “we are still looking to acquire funding for the Poole Harbour Port works to provide the infrastructure for freight traffic to start, this traffic being largely aggregates traffic. Over the last 6 months or so, the branch line has been put in a state of readiness by our maintenance teams, this is an ongoing process and includes the bridge inspections that you have referred to.
We remain hopeful we will see freight traffic return to Poole via the Hamworthy Branch and would predict 2025 for this if everything falls into place although this as you can imagine is always subject to change.”
Bournemouth, Christchurch and Poole (BCP) Council are reviewing its strategic transport priorities and welcome our input. Recommendations for potential transport improvement schemes have been grouped into five clusters and relate to locations within the BCP Boundary, including local railway stations, Poole Port Expansion and the reopening of the Hamworthy Branch along with two further clusters with wider scope where one of these includes the South West Main Line.
Thanks for reading. It was good to meet up with fellow enthusiasts at the weekend as we all took the opportunity to watch the toing and froing of the engineering works. Be seeing you!
Swanage resident Class 33 No. 33111 tows Adams T3 4-4-0 No. 563 from Norden to Swanage – 30/08/2023
August 30th 2023 to September 5th 2023
Wednesday August 30th was a busy day for local rail activity in our part of Dorset with a Class 458/5 unit drag scheduled from Bournemouth depot and the return of a Victorian era “Top Link” engine in the form of London & South Western Railway (LSWR) Adams T3 4-4-0 No. 563 to the Swanage Railway following her six year overhaul. And with both these things scheduled to happen 17 miles apart at relatively the same time it was time for a plan!
It was my intention to pop over to Branksome railway station around half four to see the arrival of GBRf Class 57 No. 57305 and Class 47 No. 47749 ‘City Of Truro’ arriving with barrier wagons working 5Z72 1548 Eastleigh East Yard to Bournemouth T&R.S.M.D in preparation for another Class 458/5 electric multiple unit move to Widnes Transport Tech where the units are being modified and refurbished for future use by South Western Railway (SWR). Following this, it would be a half hour drive to Norden where T3 No. 563 would be waiting to be towed down to Swanage. Once again, Jamie very kindly provided transport and good company with Yoshi sitting this adventure out at home.
On arrival at Branksome we followed the progress of 5Z72 via Real Time Trains (RTT) and Open Train Times (OTT) which showed the train getting progressively later. This meant that is was likely to arrive at platform 2 the same time as a passenger service was scheduled on platform 1. So careful consideration had to be made in order for the GBRf working to not be blocked from view if I opted for the wrong platform from which to see the train. I played it safe and wandered off to the London end of platform 2 in time to see the Class 57 round the corner just as the service train crept up behind me on the adjacent track. I wasn’t to be so lucky on the return working however!
GBRf Class 57 No. 57305 climbs into Branksome working 5Z72 1548 Eastleigh East Yard to Bournemouth T&RSMD – 30/08/2023
It’s been approximately 20 years since the most recent Class 57 conversions from Class 47’s were out-shopped by Brush Traction at Loughborough and 32 of the 33 rebuilds during the late 1990’s and early 2000’s are still in existence following the scrapping of No. 57004 in July 2023, this being the first and to date, only Class 57 to be broken up.
GBRf Class 47 No. 47749 ‘City of Truro’ awaits permission to reverse 5Z72 1548 Eastleigh East Yard to Bournemouth T&RSMD into the depot – 30/08/2023
Cameras safely stowed away we drove off through Poole and Wareham, where we were stuck behind slow moving motorhomes and bus services. Narrowly avoiding being further delayed by a herd of cows crossing the road at Stoborough, we arrived at Norden well before Class 33 No. 33111 arrived from Swanage towing a brake van to collect No. 563. The Victorian 4-4-0 looked amazing, even from a distance, as we observed the locomotive from the road bridge looking across to Arne Road siding. The final Diesel Multiple Unit service of the day from Wareham to Corfe castle was waiting clearance at the road crossing into Norden station and once this had passed through the area, we didn’t have too long to wait until the Crompton arrived. In fact the whole operation of reversing into the siding and coupling up to the T3 was done ahead of the proposed timings and once the consist pulled away we moved on to our next vantage point. We had plenty of time as it was planned for the diesel locomotive to run around the T3 and brake van in Norden station so the Class 33 was leading for the onward journey to Swanage. With top speed a sedate 15mph for the 33 and T3 pairing, we took a position overlooking the Grade II listed viaduct in the shadow of Corfe Castle. We didn’t know if we’d be in for a long wait as things were, at that time, around an hour ahead of schedule. As luck would have it, we didn’t have long before the locomotives came into view.
Looking stunning in her restored Drummond passenger green livery, Adams T9 4-4-0 No. 563 has been reunited with her tender and awaits the arrival of the train to tow her to Swanage – 30/08/2023Class 33 No. 33111 slowly draws T3 No. 563 slowly out of Arne Road Siding – 30/08/2023Adams T9 4-4-0 No. 563 being moved from Norden to Swanage – 30/08/2023Adams T9 4-4-0 No. 563 is towed across the Grade II listed viaduct at Corfe Castle by Class 33 No. 33111 – 30/08/2023
T3 No.563 was completed in March 1893 and was allocated new to Nine Elms shed, with moves to Guildford and Eastleigh over the following years. After an overhaul in 1935, she was transferred to Salisbury where she was looked after by shed staff, performing as station pilot or working slow trains to Bournemouth until being reallocated to Eastleigh in February 1938. She was withdrawn in March 1939 following her failure whilst working a Fawley goods train. However, with the onset of World War II she was reinstated into traffic being allocated to both Basingstoke and Eastleigh before being withdrawn again in 1945 following cessation of hostilities in Europe. She was resurrected yet again three years later in 1948 as an exhibit at London Waterloo’s centenary celebrations where she represented the LSWR. There then followed periods of storage in the electric carriage shed at Farnham, and at Tweedmouth before being restored at Eastleigh prior to moving to the Clapham transport museum in 1961 as part of the National Collection. From 1975, she was subsequently displayed at York and Shildon and took part in theatre productions of “The Railway Children” in London and Toronto before being disposed of by the National Railway Museum in 2017, when following a series of negotiations it was agreed to transfer ownership of No. 563 to the Swanage Railway Trust.
No. 563 has been extensively restored at the Flour Mill near Lydney in the Forest of Dean, Gloucestershire with the tender being restored separately at Herston Works, Swanage. Restoration started in November 2017, at the cost of £650,000. Having passed her boiler exam in July 2023 and moving under her own power for the first time in 75 years, No. 563 was transported by road to Purbeck arriving early morning on Wednesday August 30th. Resplendent in lined-out 1890’s Drummond passenger green livery, the T3 was reunited with her tender prior to making the journey by rail from Arne Road Siding at Norden in the company of “Crompton” Class 33 No. 33111. She will undergo inspections and testing prior to entering operational service. Unfortunately while the locomotive was being moved at low speed to Swanage, both coupling rods started to run warm. Before testing can resume, precautionary checks will be required and the re-machining of the coupling rods bushes. Commissioning work will continue at Herston while this is being done. It is hoped that No. 563 will haul her first passenger train in 75 years on the Swanage Railway to mark the centenary of the Southern Railway and the 185th anniversary of the formation of the London and South Western Railway in 2023, but no date has yet been confirmed.
No. 563 fills a gap in the Swanage Railway fleet as the class hauled trains from London to Swanage from the 1890’s through to the 1930’s and represents an image of what the railways would have been like during the industrial and social development of Dorset during the 19th Century.
Adams T3 4-4-0 No. 563, Swanage Railway – 30/08/2023
As things had happened smoothly and well ahead of schedule, following a quick consult of Google Maps, we decided we had enough time to head back to Branksome and see the Class 458/5 drag departing Bournemouth depot. On our return to Branksome, we checked RTT and OTT once again, but it was to be a good 17 minutes after the allotted time that Class 57 No. 57305 rolled back into the station working as 5Q72 1926 Bournemouth T&R.S.M.D to Wembley Receptions 1-7. Although diagrammed to reverse at platform 2, the train in fact arrived on platform 1. Again decisions had to be made on where to stand in order to get a shot of the GBRf locos and SWR EMU. All went well until departure time when, having returned to the London end of platform 2, a Class 444 working a service train arrived just as the Class 47, now leading the train out, powered up and departed. You win some, you lose some!
GBRf Class 57 no. 57305 emerges from Bournemouth depot working 5Q72 1926 Bournemouth T&R.S.M.D to Wembley Receptions 1-7 – 30/08/2023Class 458/5 No. 458525, part of 5Q72 1926 Bournemouth T&R.S.M.D to Wembley Receptions 1-7, stands in the platform at Branksome on the way to Widnes Transport Tech for conversion and refurbishment – 30/08/2023
Class 458 EMU move from Bournemouth T&RSMD – 30/08/2023
On Sunday September 3rd, we took the opportunity to go and bark at some CrossCountry HST’s in Somerset. With only a few weeks remaining of scheduled XC High Speed Train workings we drove over to Highbridge and met up with @smithy.377 (check out his excellent Instagram account!).
Once an important centre on the Somerset & Dorset Joint Railway (S&DJR) accommodating their locomotive works, Highbridge survives today as a top on the Bristol to Taunton Main Line operated by Great Western Railway (GWR). The original station opened on 14th June 1841, when the Bristol and Exeter Railway (B&ER) opened its broad gauge line to Bridgwater. The B&ER was later amalgamated into the Great Western Railway (GWR) on 1st January 1876.
The Somerset Central Railway (later absorbed into the S&DJR) opened to Glastonbury on 28th August 1854 but was worked by the B&ER for the first few years as it was also originally built to Brunel’s broad gauge. Separate platforms were provided for each railway and a connection between the was two situated in the goods yard. The layout eventually consisted of two terminal platforms and two through platforms to service an extension line that continued via Highbridge Wharf (where most of the S&DJR goods traffic was also handled) and onwards to Burnham On Sea extending the line two or three miles westwards which opened on 3rd May 1858.
To reach the extension, the S&DJR line crossed the B&ER main line on the level just north of the road bridge, by means of a special ‘diamond crossing’ over the main line and a gated level-crossing over the A38. The Burnham line was a key element in the original planning for the Somerset and Dorset line and was built with the expectation of picking up passengers from paddle-steamer ferries from South Wales and transporting them to the south coast of England with Burnham On Sea railway station, essentially a terminus, also including a through platform allowing services to travel on to a 900ft S&DJR built stone pier on the River Severn/River Parrett estuary from where the steamers would sail. Railway operations onto the pier ceased in 1888 although the pier continued in use for shipping until the 1950’s.
Burnham On Sea effectively closed when regular passenger services were curtailed at Highbridge on 28th October 1951. Excursion traffic continued until 1962, and the goods depot remained open until 1963 with all rail traffic ceasing in 1966. The station building, main platform and goods shed were all subsequently demolished. The excursion platform remained on the derelict site for over a decade, until the former track bed eastwards was developed into Marine Drive, a road which has helped ease traffic flowing into the town.
The location of the station itself was on the junction of Old Station Approach and Abingdon Street, and the former goods yard is now a small car park. An adjacent pub on the High Street was renamed the “Somerset & Dorset”. The local RNLI station and yard occupy land to the south and east of the former main station building, adjacent to the site of the former excursion platform. A B&M store occupies the seaward-west side. To remember its railway past, there are various features which have been installed by the local railway Heritage Group, notably a replica semaphore signal on Old Station Approach near the entrance to the High Street Car Park, a buffer stop on the corner of South Esplanade and Pier Street located very near to the site of original railway terminus, a station signboard and replica signal box which stands on what was known as the excursion platform, and a locomotive shaped weathervane on the town green. The original signal box which once stood alongside the platforms has been restored and is now based at Washford on the West Somerset Railway.
Burnham On Sea station sign marking the site of the former excursion platform – 03/09/2023Yoshi enjoys the shade provided by the replica signal box at Burnham On Sea – 30/08/2023Plaque explaining the replica signal box at Burnham On Sea – 30/08/2023
Returning to Highbridge the S&DJR locomotive works closed in 1930 after the motive power of the line was taken over by the London Midland and Scottish Railway (LMS), whilst its joint-venture owning partner the Southern Railway (SR) took over civil engineering and line operations. a small engine shed remained open until the Somerset & Dorset line and platforms finally shut in 1966. All of the original B&ER/GWR and S&DJR station buildings have all since been demolished, replaced on current platforms by metal and glass shelters. There is also no trace of the former S&DJR trackbed, platforms, engine shed or works, all of which are now beneath new housing to the east of platform 1. A couple of old wagon wheels sit on a short length of track on a plinth marking the past history of the site.
Wheel sets mark the area where the S&DJR yard and works once stood at Highbridge – 03/09/2023Old rail at Highbridge – 30/08/2023
To see film of Highbridge and Burnham in the early 1960’s follow this link: https://www.bbc.co.uk/iplayer/episode/b03495yn/lets-imagine-a-branch-line-railway-with-john-betjeman. First transmitted in 1963, John Betjeman looks at the Evercreech Junction to Burnham On Sea railway line, providing a unique profile of a working steam branch line railway as he travels along the original part of the Somerset Central Railway. Examining towns and stations along the way, Betjeman laments the tragic decline of steam railways. The journey culminates with a stroll around Highbridge Wharf.
Twenty odd years ago I visited Burnham On Sea regularly for work based at Highbridge Radio Station (Portishead Radio). The radio station, which operated the world’s largest and busiest maritime radio service, closed in April 2000, having initially operated from a site near Devizes in 1920. At its peak, in the late 1970’s and early 1980’s, over 300 staff were employed at the Highbridge site. The station buildings were demolished in 2007 and the Mulholland Park housing estate was built on the site.
Motive power through Highbridge is currently provided by GWR Intercity Express Trains (IET) and soon to be retired HST Castle Sets with one stopping train in each direction each hour. Passing CrossCountry Voyager sets will continue after the retirement of the XC HST’s.
CrossCountry Class 43 HST power car No. 43007 leads 1V48 0811 Leeds to Plymouth through Highbridge – 03/09/2023CrossCountry Class 43 HST power car No. 43378 at the head of 1S53 1327 Plymouth to Edinburgh approaches Highbridge railway station – 03/09/2023CrossCountry Class 43 HST power car No. 43321 at the rear of 1S53 1327 Plymouth to Edinburgh speeds through Highbridge – 03/09/2023Celebrity BR liveried CrossCountry Class 43 HST power car No. 43008 working 1S55 1427 Plymouth to Leeds on the approach to Highbridge – 03/09/2023GWR Castle Class HST No. 43155 with the stopping 2U20 1050 Penzance to Cardiff Central service approaches Highbridge – 03/09/2023GWR Castle Class HST No. 43155 at the rear of 2U20 1050 Penzance to Cardiff Central awaiting departure from Highbridge – 03/09/2023GWR Castle Class HST No. 43189 working 2C79 1400 Cardiff Central to Penzance passes under the road bridge on the approach to Highbridge from the Bristol direction – 03/09/2023GWR Castle Class HST No. 43016 2C79 1400 Cardiff Central to Penzance sits at the platform in Highbridge – 03/09/2023GWR InterCity Express Train (IET) No. 800004 at Highbridge working 2C77 1300 Cardiff Central to Penzance – 03/09/2023CrossCountry Voyager Class 220 DMU No. 220003 approaches Highbridge with 1S47 1027 Plymouth to Edinburgh – 03/09/2023CrossCountry Voyager Class 220 DMU No. 220003 1S47 1027 Plymouth to Edinburgh passing through Highbridge – 03/09/2023CrossCountry Voyager Class 220 DMU No. 220006 1M45 1049 Paignton to Manchester Piccadilly at Highbridge – 03/09/2023CrossCountry Voyager Class 220 DMU No. 220021 1V56 1101 Leeds to Plymouth powers through Highbridge – 03/09/2023With the leaves on the trees starting to display autumnal colours, CrossCountry Voyager Class 220 DMU No. 220012 forming 1V54 0935 York to Plymouth passes Highbridge – 03/09/2023GWR IET No. 800304 forming 1C22 1630 London Paddington to Plymouth at Taunton East Junction – 03/09/2023CrossCountry Class 43 HST power car No. 43357 1V62 1105 Edinburgh to Plymouth catches the last rays of sun at Taunton East Junction – 03/09/2023CrossCountry Class 43 HST power car No. 43303 at the rear of 1V62 1105 Edinburgh to Plymouth approaching Taunton – 03/09/2023
XC HST’s in Somerset – 03/09/2023
As I was in the Poole area on Monday I took the opportunity of getting a glimpse of one of the Class 701 units; No. 701021, on its latest mileage accumulation run, working as 5Q51 1115 London Waterloo to Staines Up Loop. This service runs to Poole Storage Sidings where the train reverses. The 701’s are still to enter revenue earning service with South Western Railway.
Class 701 No. 701021 stands at Poole working 5Q51 1115 London Waterloo to Staines Up Loop – 04/09/2023
Video of Class 701 No. 701021 at Parkstone and Poole working 5Q51 1115 London Waterloo to Staines Up Loop – 04/09/2023
Tuesday evening saw the return of the GBRf pairing of Class 57 No. 57305 and Class 47 No. 47749 ‘City Of Truro’ with another Class 458 EMU drag from Widnes Transport Tech to Bournemouth depot. This time, I elected to see the train passing Bournemouth instead of my usual spot at Branksome. After a coffee from the Pumpkin buffet on platform 2, I walked through the car park which was once the site of Bournemouth steam shed and up to Beechey Road bridge which gives a view back towards the railway station. While I was in Bournemouth, I took the opportunity of photographing regular train movements, including South Western Railway (SWR) Class 444’s, Class 450’s and CrossCountry Voyager DMU’s.
SWR Class 444 No. 444025 awaiting departure from Bournemouth working 1W28 1703 Weymouth to London Waterloo as Class 450 No. 450088 passes as 1B45 1535 London Waterloo to Poole – 05/09/2023Occupying bay platform 1, SWR Class 450 No. 450063 prepares for departure with 1B68 1802 Bournemouth to Basingstoke – 05/09/2023SWR Class 444 No. 444003 on the approach to Bournemouth with the 1W70 1720 Weymouth to London Waterloo service – 05/09/2023SWR Class 444 No. 444039 works 1W72 1820 Weymouth to London Waterloo at Bournemouth – 05/09/2023SWR Class 444 No. 444045 at Bournemouth Middle Sidings – 05/09/2023Having arrived from Manchester Piccadilly, CrossCountry Voyager Class 221 No. 221133 worked 5022 1919 Bournemouth to Bournemouth Middle Sidings before forming the 1M78 1945 departure from Bournemouth to Birmingham New Street – 05/09/2023GBRf Class 57 No. 57305 hauling refurbished SWR Class 458 No. 458405 with Class 47 No. 47749 ‘City Of Truro’ at the rear passes through Bournemouth as 5X65 1435 Wembley Receptions 1-7 to Bournemouth T&RSMD. The locomotives and barrier coaches retuned to Eastleigh later that evening – 05/09/2023
X65 1435 Wembley Receptions 1-7 to Bournemouth T&RSMD.- 05/09/2023
Britain’s busiest railway stations have been identified following the analysis of data for 2,616 locations, and Bournemouth came top in the Dorset with 5616 passengers per day and the 190th station in the UK. Bournemouth has a performance ranking of 1908. The analysis of National Rail data, collated by On Time Trains Stations, is ranked by a performance score, calculated based on service punctuality and cancellation frequency.
Further afield, it has been announced that TransPennine Express (TPE) will withdraw their troubled Nova 3 Class 68 hauled trains with effect from the December 2023 timetable change. We mention this, as back in 2016 prior to the TPE contract being awarded to FirstGroup, it was widely reported that the Department for Transport (DaFT) was eager to utilise de-motored Class 442 “Wessex Electric” electric multiple units hauled by Class 68 locomotives on Trans Pennine services. This plan, however, developed into an order for 66 new MK 5a carriages. The “Wessex Electrics” were introduced when the Bournemouth to Weymouth route was electrified and imho are amongst the best electric multiple units ever built. All this gives me an excuse to share some images of TPE liveried Class 68’s along with a few local photos of Class 442 EMU’s in South West Trains days.
68027 ‘Splendid’ at York – 18/06/202168024 ‘Centaur’ at York -30/08/202068025 ‘Superb’ at York- 30/08/202068019 ‘Brutus’ at York – 18/06/202168032 ‘Destroyer’, York – 17/06/202168032 ‘Destroyer’ at York – 18/06/2021South West Trains Class 442 No. 442415 at Weymouth. FM Rail owned Class 31 No. 31128 ‘Charybdis’ waits to depart with a “John Lewis Partnership” private charter back to London Victoria – 29/07/2006South West Trains Class 442 No. 442418 at Bournemouth – 28/12/2006De-branded Class 442 No. 442416 at Branksome – 03/05/2007
Yoshi has been ship spotting at Poole Quay this week as two steamships, both originally from Glasgow, namely SS Shieldhall and PS Waverley, visited.
SS Shieldhall is a preserved steamship that operates from Southampton. She is one of the last reciprocating steam engined ships built, using technology that dated back to the last quarter of the 19th century and which was obsolete at the time of her construction. She spent her working life as one of the “Clyde sludge boats”, making regular trips from Glasgow to dump treated sewage sludge at sea – 04/09/2023 PS Waverley is the last seagoing passenger-carrying paddle steamer in the world. Built in 1946, she sailed from Craigendoran on the Firth of Clyde to Arrochar on Loch Long until 1973 – 04/09/2023
Thanks for making it this far! I often say I ignore the Voyager units, but think I’ve more than made up for it this time around. Comments and corrections gratefully received. Be seeing you!
LMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ working the final 2023 Railway Touring Company organised “Dorset Coast Express” 1Z92 0845 London Victoria to Weymouth – 17/08/2023
August 16th 2023 to August 23rd 2023
For a long while I’ve been meaning to climb up to the railway line accessed from the old main road between Dorchester and Weymouth, just north of Upwey village, with the aim of photographing passing trains. This was once the site of Upwey Wishing Well Halt, and although the steps survive either side of the railway line, nothing now exists of the platforms which once stood here. Opened by the Great Western Railway (GWR) on 28th May 1905 and served by rail motor trains between Weymouth and Dorchester, the station survived until 7th January 1957 when it was closed. Originally the station was a two platform timber built affair with corrugated iron pagoda style shelters. The nearby tourist attraction of Upwey Wishing Well brought many visitors by rail in the early years of the halt’s existence, but increasing competition from road transport and buses which could deposit their passengers closer to the Well itself saw an ever diminishing use by rail passengers. The last remnants were swept away during the 1988 Bournemouth to Weymouth electrification scheme. Locked gates and fences protect observers from the railway, preventing trespass but affording a good view up to Bincombe tunnel. I chose Thursday 17th August to visit as there were two special excursion trains due to pass in relatively quick succession. Grateful thanks to Jamie for the lift down to Upwey. A few days later I returned to Upwey and the actual Wishing Well to celebrate my mum’s 90th birthday. Happy days.
Still in South Western Trains livery, South Western Railway Class 444 EMU No. 444045 runs past the site of the former Upwey Wishing Well Halt with 1W21 1035 London Waterloo to Weymouth – 17/08/2023Class 57 No. 57601 ‘Windsor Castle’ heads up “The Northern Belle: Weymouth Harbour” 1Z79 0711 Coventry to Weymouth – 17/08/2023165137 – 2V68 1328 Weymouth to GloucesterLMS Jubilee 4-6-0 No. 45596 ‘Bahamas’ works the final 2023 “Dorset Coast Express” 1Z92 0845 London Victoria to Weymouth coasting down Bincombe Bank – 17/08/2023West Coast Railways Class 57 No. 57313 ‘Scarborough Castle’ working 5Z80 1333 Weymouth to Yeovil Pen Mill empty coaching stock movement designed to free up space in Weymouth because of the two excursion trains scheduled for the day works up Upwey Bank towards Bincombe Tunnel – 17/08/2023
Video from 17th August 2023 including the following: 444034 – 1W61 1005 London Waterloo to Weymouth and Poole 444029 – 1W20 1303 Weymouth to London Waterloo 444045 – 1W21 1035 London Waterloo to Weymouth 57601/57313 – 1Z79 0711 Coventry to Weymouth 444034 – 1W62 1320 Weymouth and Poole to London Waterloo 165137 – 2V68 1328 Weymouth to Gloucester 45596/ 47802 – 1Z92 0845 London Victoria to Weymouth 57313/57601 – 5Z80 1333 Weymouth to Yeovil Pen Mill 47802/45596 – 1Z93 1636 Weymouth to London Victoria 57601/57313 – 5Z82 1641 Yeovil Pen Mill to Weymouth – with thanks to G E Barrett for video clips at Dorchester
Later on the 17th I headed off to Branksome to see an engineers train pass through bound for Poole. On this occasion the train was worked by GBRf and was top and tailed by class 66 locomotives. On my way home, I popped in at Poole to see the locos and ballast hoppers awaiting deployment.
GBRf Class 66 No. 66791 6G28 2304 Eastleigh East Yard to Poole – 18/08/2023GBRf Class 66 No. 66749 ‘Christopher Hopcroft MBE 60 Years Railway Service’ at the rear of 6G28 2304 Eastleigh East Yard to Poole – 18/08/2023
The following Tuesday and I was once again setting off for more midnight engineering train shenanigans, this time with DB Cargo class 66’s in charge of a train of new rail which was destined for the Christchurch – Pokesdown area.
DB Cargo Class 66 No. 66028 at the head of 6N65 2349 Eastleigh East Yard to Christchurch – 23/08/2023DB Cargo Class 66 No. 66067 at the rear of 6N65 2349 Eastleigh East Yard to Christchurch having run through the station – 23/08/2023
Video of Dorset engineers train amongst every day railway movements – August 2023
Hamworthy Branch Update:
Out walking Yoshi around Hamworthy and I noticed a planning application notice fastened to the fence close to where the original Poole station once stood. What caught my eye was a variation of conditions quoted within the notice allowing for a “National Rail parking area” as part of a new development on the former James Brothers Site on Station Road.
Planning application notice – August 2023Diagram of redevelopment plans of the former James Brothers Site on Station Road, Hamworthy varied to align with new plan numbers, including a revised drainage strategy, wording changed with amended parking space numbering to allow for a dedicated Network Rail parking area which includes a set of gates to allow access to railway land to the south of the site. As shown by the plans, these will be flood-gates at a minimum height of 3.6m – August 2023
From The Archive:
I have to admit to being partial to an engineering train. Every night I lie in bed, the brightest colours fill my head, a million dreams are keeping me awake, I think of what the world could be. No, hang on, that’s from “The Greatest Showman”. Anyway, back in April 2015 there was no need to dream of engineers trains as eleven of them found their way to Upwey on Saturday 11th, following an earlier light engine visit on the 9th which ran as a crew route refresher for Colas. The purpose of this engineering possession was for the relaying of the up line between Upwey station and Bincombe Tunnel. Trains ran in order as follows; No. 66050 top and tailed with No. 66101, No. 70805, No. 66016, No. 70807, No. 70808, No. 66014, No. 66177, No. 66705, No. 70809, No. 66204 and finally train eleven with No.’s 66074 and 66174.
EWS Class 66 No. 66016 at Upwey – 11/04/2015Class 66 Np. 66050 and Class 70 No. 70805 at Weymouth – 11/04/2015Class 70 No. 70805 in Weymouth station – 11/04/2015Class 66 No. 66016 on the approach to Weymouth – 11/04/2015Class 66 No. 66050 departs Weymouth with a train of track panels – 11/04/2015GBRf Class 66 No. 66705 arrives at Dorchester South with a train of new ballast – 11/04/2015A view over to Upwey railway station with Class 66 No. 66101 in DB red livery – 11/04/2015Class 66 No. 66204 near Upwey – 11/04/2015Class 70 No. 70809 arrives into Dorchester – 11/04/2015A view towards Weymouth looking down to the site of Upwey Wishing Well Halt – 11/04/2015Class 70 No. 70807 at rest in Weymouth station – 11/04/2015Class 70 No. 70808 between to trains in Weymouth – 11/04/2015GBRf Class 60 No. 66705 pokes out of Bincombe Tunnel – 11/04/2015Road/rail machines watched by Class 66 No. 66014 near Upwey – 11/04/2015Class 66 No. 66177 at Upwey – 11/04/2015DB liveried Class 66 No. 66101 at Upwey – 11/04/2015Class 66 No. 66174 at a stand on Bincombe Bank- 12/04/2015Another view looking towards Weymouth with a track machine where Upwey Wishing Well Halt was once located – 12/04/2015Class 66 No. 66074 near to the location of Monkton and Came Halt railway station which opened in 1905 as Came Bridge and closed in 1957 – 12/04/2015
Starting with No. 66174 which departed Dorchester South mid-afternoon most of the trains returned to Eastleigh on Sunday 12th in reverse order with the last running early on Monday 13th.
Class 66 No. 66074 at Dorchester South departs for Eastleigh. The Brewery Square development is being built in the background – 12/04/2015
A continuation of the work was carried out over three successive evenings on 13th, 14th and 15th April, with two engineers trains allocated to this. On the evening of Monday 13th No. 66050 worked train No. 1 followed by top and tail Class 70 No.’s 70808 and 70809, the same loco’s repeated the moves the following day. However on Wednesday 15th No. 66170 turned up with the same Class 70’s remaining on the second train (With thanks to “The Corkscrew” the newsletter of The Wimborne Railway Society for the meticulous notes!)
That’s us for this week. Thanks, as ever, for reading and for your comments and corrections which are always welcome, except the ones with links to dubious websites obviously (these can, however, be obtained by writing to me on the back of a ten pound note). Be seeing you!
Yoshi wanting to play ball rather than help compile this weeks blog!
